Phoenix Contact IC 2.5/2-STGF-5.08 Series Pluggable Terminal Block, 2 Contacts, 5.08 mm Pitch, 1 Row, 12A, 320V 1825501
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 12A |
| Length | 19.2mm |
| Model | 1825501 |
| Depth | 15mm |
| Width | 20.28mm |
| Housing Material | Polyamide |
| Series | IC 2.5/2-STGF-5.08 |
| Number of Rows | 1 |
| Contact Surface | Tin |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 2 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
| PCB connector, nominal current | 12 A, rated voltage (III/2): 320 V, number of positions: 2, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin |
Key Features
- Pluggable terminal block designed for PCB connections with a 5.08 mm pitch.
- Features a screw connection method with a tension sleeve for secure wiring.
- Supports 2 contacts in a single row with straight body orientation and male gender.
- Rated for 12A nominal current and up to 320V voltage in Class III/2 applications.
- Constructed from polyamide material for durability and flame resistance.
- Accommodates wire sizes from 2 mm² up to 2.5 mm², 24 AWG to 12 AWG.
- Green coloured housing with RoHS compliance for safety and environmental standards.
- Compact dimensions of 19.2 mm length, 20.28 mm width, and 15 mm depth.
Product Description
Phoenix Contact IC 2.5/2-STGF-5.08 Series Pluggable Terminal Block, model 1825501, is a precision-engineered PCB terminal block offering reliable connection for industrial electronics. With a 5.08 mm pitch and 2 contact positions, it is ideally suited for modular applications requiring frequent PCB changes and secure cable mounting. The screw connection method with integrated tension sleeve ensures robust and touch-proof electrical connections without the need for specialized tools.
Suitable for automation, security, and modular electronics, this terminal block is rated for 12A nominal current and up to 320V voltage (III/2), making it appropriate for a range of high-performance tasks. The inverted connector design enhances operational safety, and coding systems protect devices from incorrect connections. Its polyamide housing meets UL94 V-0 flame resistance, self-extinguishing within 10 seconds if exposed to flame.
Designed for flexible wiring, the terminal block accommodates wire sizes from 2 mm² up to 2.5 mm² (24 AWG to 12 AWG), making it compatible with a wide variety of cabling standards. The screw termination method enables fast installation and removal while ensuring a firm mechanical connection. Straight body orientation and male connector gender add to its versatility in PCB layouts and cable-mounting tasks.
Its compact form factor (19.2 mm x 20.28 mm x 15 mm) saves space on PCBs, and the green colour coding assists with identification. The block is fully compliant with RoHS environmental standards, signifying a commitment to ecological safety and lead-free manufacturing. Tin-plated contact surfaces further enhance its electrical performance and resistance to corrosion.
Commonly used in industrial automation, electronic equipment, instrumentation, and modular PCB-based systems, Phoenix Contact terminal blocks have a reputation for durable construction, easy handling, and reliable performance. Manufactured in Germany, this unit delivers robust service in demanding environments.
Browse related Phoenix Contact terminal blocks and connectors in the Electronics Components category on EnvMart for comprehensive automation and PCB connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a nominal current of 12A.
This terminal block can handle a maximum voltage of 320V.
The pitch size of the contacts is 5.08 mm.
It accommodates wire sizes from 2 mm² to 2.5 mm², or 24 AWG to 12 AWG.
It uses a screw connection method with a tension sleeve for secure wiring.
The dimensions are 19.2 mm in length, 20.28 mm in width, and 15 mm in depth.
The housing is made from polyamide material.
Yes, it is compliant with RoHS environmental standards.
The connector has a straight body orientation.
It has 2 contacts in a single row.
The terminal block is green in color.
It is manufactured in Germany.
