TDK Standard Metal Oxide Varistor 530 pF 50 A Clamping 2970 V Varistor 360 V B72214S0231K101

Free Delivery in India | Lowest Global Shipping Charges

TDK Standard Metal Oxide Varistor 530 pF 50 A Clamping 2970 V Varistor 360 V B72214S0231K101



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	10mm
Brand	TDK
Material	Metal
THICKNESS	4.7mm
Length	15.5mm
Model	B72214S0231K101
Depth	18.5mm
Mount Type	Lead
Series	Standard
Energy Rating	1J
Maximum Operating Temperature	105°C
Capacitance	530pF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	1465V dc
Standards/Approvals	UL, CSA, CQC, VDE, IEC
Termination Style	Radial
Lead Pitch	7.5mm
Maximum AC Voltage	1100V ac
Clamping Voltage VC	2970V
Clamping Current	50A
Maximum Surge Current	4.5kA
Varistor Voltage	360 V

Key Features

Standard metal oxide varistor with lead mounting style for easy circuit integration.
Operates reliably between temperatures of -40°C and 105°C.
Radial termination and a lead pitch of 7.5 mm provide secure electrical connections.
Rated for maximum AC voltage of 1100 V and DC voltage up to 1465 V.
Energy rating of 1 Joule suitable for transient voltage suppression applications.
Constructed from metal material with flame-retardant coating for enhanced safety.
Compact dimensions with 10 mm diameter and 15.5 mm length allow for versatile PCB mounting.
Complies with UL, CSA, CQC, VDE, and IEC standards ensuring quality and safety.

Product Description

TDK B72214S0231K101 is a standard metal oxide varistor designed for transient voltage suppression in electronic circuits. Featuring a capacitance of 530 pF and a clamping current of 50 A, it provides reliable protection against voltage spikes. The device has a clamping voltage of 2970 V and a varistor voltage rating of 360 V, making it suitable for a range of power and signal applications in industrial and commercial electronics.

This varistor is constructed with robust metal material and coated with a flame-retardant layer to enhance safety during high surge events. It is designed for lead-type mounting, utilizing radial termination and a lead pitch of 7.5 mm for solid connections in printed circuit boards.

Operating efficiently within a temperature range from -40°C to 105°C, this varistor withstands maximum AC voltages of 1100 V and DC voltages up to 1465 V. Its physical characteristics include a diameter of 10 mm, length of 15.5 mm, thickness of 4.7 mm, and depth of 18.5 mm, which make it compact and suitable for varied PCB layouts.

The varistor meets multiple international standards including UL, CSA, CQC, VDE, and IEC certifications, ensuring compliance for industrial electronic applications. Its energy rating of 1 Joule suits it for protecting sensitive components against electrical surges and transient events.

Typical industrial applications include surge protection in power supplies, consumer electronics, telecommunications, and automotive electronics. Its flame-retardant coating adds an extra layer of safety in environments where thermal events may occur.

Standard metal oxide varistor with lead mounting style for easy circuit integration. Operates reliably between temperatures of -40°C and 105°C. Radial termination and a lead pitch of 7.5 mm provide secure electrical connections.

Rated for maximum AC voltage of 1100 V and DC voltage up to 1465 V. Energy rating of 1 Joule suitable for transient voltage suppression applications. Constructed from metal material with flame-retardant coating for enhanced safety.

Compact dimensions with 10 mm diameter and 15.5 mm length allow for versatile PCB mounting. Complies with UL, CSA, CQC, VDE, and IEC standards ensuring quality and safety. Explore the Electronics Components category on EnvMart for more TDK Varistors and related surge protection components.
