Cynergy3 PCB Reed Relay, 24V DC Coil, SPST Contact Configuration, 1000V DC Max, 1A Max, 1550 Ω Coil Resistance

Free Delivery in India | Lowest Global Shipping Charges

Cynergy3 PCB Reed Relay, 24V DC Coil, SPST Contact Configuration, 1000V DC Max, 1A Max, 1550 Ω Coil Resistance

Name: Cynergy3 PCB Reed Relay, 24V DC Coil, SPST Contact Configuration, 1000V DC Max, 1A Max, 1550 Ω Coil Resistance
Brand: Cynergy3
SKU: 142112
Price: 28.52 USD
Availability: InStock



Category Reed Relay Brand Cynergy3 Condition New

Specifications

Country of Origin	China
Brand	Cynergy3
Height	12mm
Length	30mm
Model	Cynergy3
Operating Time	1ms
Mount Type	PCB
Series	S8
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Minimum Operating Temperature	-40°C
Terminal type	PCB Terminal
Contact Resistance	150mΩ
Standards/Approvals	UR
Coil Resistance	1550Ω
Isolation Coil To Contact	7kV

Key Features

Designed for PCB mounting with standard PCB terminal pins for secure installation.
Coil resistance of 1550 Ω ensuring precise control and efficient coil operation.
Operates reliably within a temperature range of -40°C to +85°C.
Offers fast operating time of 1 millisecond, including bounce.
Provides electrical isolation of 7kV between coil and contacts for safety and performance.
Features low contact resistance of 150 milliohms for minimal signal loss.
Constructed with rhodium contact material to resist wear, corrosion, and heat exposure.
Supports high switching power up to 100VA for industrial applications.

Product Description

Cynergy3 S8-2405V/RS PCB Reed Relay is a high-performance relay designed for electromagnetic control of high-voltage reed switches with a 24V DC coil and Single Pole Single Throw (SPST) configuration. It delivers switching capability up to 1000V DC maximum voltage and a maximum switching current of 1A, making it suitable for demanding industrial and electronic applications requiring precise and reliable control.

This relay is designed specifically for PCB mounting, featuring standardized PCB terminal pins which provide a secure and airtight seal to prevent dust ingress and ensure long-lasting reliability. The coil resistance of 1550 Ω allows efficient coil operation and precise switching performance.

The relay operates effectively in temperature conditions ranging from -40°C to +85°C, making it suitable for harsh industrial environments. It provides exceptionally fast switching speed of 1 millisecond, inclusive of bounce, ensuring reliable rapid response in control circuits.

Electrical isolation between coil and contacts is rated at 7kV, offering enhanced safety and noise immunity for sensitive electronic circuits. Contact resistance is low at 150 milliohms, minimizing power loss and ensuring efficient current conduction. The rhodium contact material ensures extended durability by resisting wear, corrosion, and heat exposure.

Rated for a switching power of up to 100VA and designed to provide a long operational lifespan of up to 10 million electrical cycles, this relay is ideal for industrial automation, control systems, electronic switching, and signal conditioning applications. Its compact size of 30 mm length by 12 mm height is suitable for applications requiring space-efficient components.

Designed for reliable and long-lasting high voltage switching. Suitable for industrial, electronics, automation, and control applications. Compact form factor ideal for PCB mounting in tight spaces. High electrical isolation and low contact resistance ensure safety and efficiency.

Durable rhodium contacts enhance reliability under heat and corrosion stress. Explore more in the Electronics & Electricals category at EnvMart to find compatible relays and related electronic components for your projects and industrial requirements.
