Cynergy3 PCB Reed Relay 24V DC Coil SPNC 7000V DC Max 2A 925Ω
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Cynergy3 |
| Height | 18.5mm |
| Length | 60mm |
| Model | Cynergy3 |
| Operating Time | 2ms |
| Mount Type | PCB |
| Series | DBT |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPNC |
| Minimum Operating Temperature | -20°C |
| Terminal type | Wire Wrap |
| Contact Resistance | 250mΩ |
| Standards/Approvals | UR |
| Coil Resistance | 925Ω |
| Coil Power | 50W |
| Switching Power | 50W |
| Isolation Coil To Contact | 17kV |
Key Features
- High voltage isolation up to 7,000V DC, suitable for advanced industrial and test equipment applications.
- SPNC (Single Pole Normally Closed) contact, supports reliable switching with up to 2A current.
- Features a 24V DC coil with a 925Ω resistance and rapid response operating time of 2 ms.
- Wire wrap terminal configuration and robust PCB mount design for ease of integration in circuit assemblies.
- Excellent low contact resistance of 250mΩ and high reliability operation for demanding scenarios.
- Wide operating temperature range from -20°C to +70°C ensures performance in various environments.
- Compact size with length 60 mm and height 18.5 mm for efficient circuit board utilization.
Product Description
The Cynergy3 DBT72405FU is a high-performance PCB reed relay engineered for demanding industrial, laboratory, and high-voltage switching applications. This model features a 24V DC coil and delivers superb isolation capabilities with a maximum voltage switching rating of 7,000V DC, making it ideal for use in advanced test equipment, cardiac defibrillators, and high-voltage power supplies where safety and reliability are paramount.
Designed with an SPNC (Single Pole Normally Closed) contact configuration and capable of supporting up to 2A switching current, this relay utilizes high vacuum reed switches with either Tungsten or Rhodium contacts. The combination delivers outstanding isolation (up to 17kV coil-to-contact) and reliable low contact resistance, ensuring minimal losses in sensitive electronic applications.
The DBT72405FU provides a fast switching operating time of just 2 ms, with a coil resistance of 925Ω and a robust switching power rating of 50W. An operating temperature range from -20°C to +70°C ensures consistent performance in a wide range of environments, from laboratory setups to demanding industrial settings.
Mounting is streamlined via a PCB configuration with a wire wrap terminal type, enabling secure and reliable integration onto printed circuit boards. The relay’s compact form factor (60 mm length, 18.5 mm height) allows for efficient layout within electronic assemblies, while UR certification according to international standards validates its safety and performance in regulated environments.
The reliability of Cynergy3 reed relays makes them widely applicable in industrial automation, high-voltage isolation, medical instrumentation, communications equipment, and high-reliability testing scenarios. Its unique combination of high voltage capability, fast switching, and robust construction distinguishes this relay in commercial and technical environments where absolute safety and precision are required.
Explore more high-performance relays, industrial components, and PCB automation solutions by browsing Cynergy3 and Reed Relay solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage switching rating for this relay is 7,000V DC.
This model features a Single Pole Normally Closed (SPNC) contact configuration.
The coil resistance of this relay is 925Ω.
The operating temperature range is from -20°C to +70°C.
The relay has a fast switching operating time of just 2 ms.
The contact resistance is 250mΩ, ensuring minimal losses in sensitive applications.
The coil power rating is 50W.
This model is designed for PCB mounting with a wire wrap terminal type.
The relay has a length of 60 mm and a height of 18.5 mm.
It provides superb isolation with a coil-to-contact isolation rating of 17kV.
The relay is certified according to UR standards, validating its safety and performance.
This relay is suitable for advanced industrial, laboratory, and high-voltage switching applications, including medical instrumentation and communications equipment.
