TDK Metal Oxide Varistor 220 pF 25 A Clamping 2970 V B72210S0271K101

Free Delivery in India | Lowest Global Shipping Charges

TDK Metal Oxide Varistor 220 pF 25 A Clamping 2970 V B72210S0271K101



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	10mm
Brand	TDK
Material	Metal
THICKNESS	5mm
Length	12mm
Model	B72210S0271K101
Depth	14.5mm
Mount Type	Lead
Series	B722
Energy Rating	1J
Maximum Operating Temperature	105°C
Capacitance	220pF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	1465V dc
Standards/Approvals	IEC, CQC, CSA, UL, VDE
Pin Count	2
Termination Style	Radial
Maximum AC Voltage	1100V ac
Clamping Voltage VC	2970V
Clamping Current	25A
Maximum Surge Current	2.5kA
Varistor Voltage	430 V

Key Features

Offers a varistor voltage of 430 V for circuit protection.
Maximum clamping voltage is 2970 V, suitable for transient voltage suppression.
Capacitance value of 220 pF ensures minimal impact on normal circuit operation.
Lead mount type with radial termination for easy PCB integration.
Material used is metal with flame-retardant coating for safety.
Durable under operating temperatures from -40°C to 105°C.
Energy rating of 1 joule for reliable surge absorption.
Compliance with IEC, CQC, CSA, UL, and VDE standards ensures product quality and safety.

Product Description

Brand TDK presents the B72210S0271K101 Metal Oxide Varistor, specifically engineered for high-performance surge protection in electronic circuits. Featuring a varistor voltage of 430 V and a high clamping voltage of 2970 V, this device effectively limits transient voltage spikes to safeguard sensitive components.

The varistor boasts a capacitance of 220 pF, maintaining circuit stability while providing high energy absorption with a rating of 1 joule. Its metal composition with a flame-retardant coating ensures safety and durability under demanding conditions.

This radial lead-mounted varistor, with a pin count of two, has a compact form factor measuring 10 mm in diameter, 12 mm in length, 5 mm in thickness, and 14.5 mm in depth. Rated for operating temperatures from -40°C to 105°C, it is ideal for industrial, commercial, and electronic manufacturing applications, including power supply units and surge protection devices.

Certified with IEC, CQC, CSA, UL, and VDE approvals, the B72210S0271K101 varistor meets stringent international standards for quality and reliability. Its maximum AC voltage rating is 1100 V, with a maximum DC voltage of 1465 V and maximum surge current capacity of 2.5 kA, making it suitable for a range of electrical protection scenarios.

Offers a varistor voltage of 430 V for circuit protection. Maximum clamping voltage of 2970 V for transient voltage suppression. 220 pF capacitance minimizes impact on circuit functionality. Lead mount with radial termination for easy PCB installation.

Metal material with flame retardant coating for enhanced safety. Operates reliably from -40°C to 105°C. Energy absorption capacity of 1 joule. Certifications: IEC, CQC, CSA, UL, VDE. Compact dimensions: 10 mm diameter, 12 mm length, 5 mm thickness, 14.5 mm depth.

2-pin design for low-profile circuit applications.

This metal oxide varistor is perfectly suited for industrial use in electronics manufacturing, power supplies, and surge protection solutions. For users seeking durable and certified transient voltage suppression devices, the TDK B72210S0271K101 offers robust performance and reliability.
