Molex C-Grid III Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0132

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0132

Name: Molex C-Grid III Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0132
Brand: Molex
SKU: 207024
Price: 1.82 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Supports 3 Amp current rating for reliable performance.
Constructed with brass contacts plated with tin for enhanced durability.
Housing made of high-quality polyester material ensuring mechanical stability.
Compatible with wire-to-board connector systems for versatile applications.
Designed for industrial, computer, medical, telecommunications, and automotive safety electronics.
Operates reliably in temperatures from -55°C up to 125°C.
Includes breakaway design to allow size customization during PCB assembly.
High pin retention force for secure mating and soldered mechanical stability.

Product Description

Molex 90120-0132 C-Grid III Series Straight Through Hole Pin Header is a single row unshrouded PCB header with 12 contacts spaced at a 2.54 mm pitch. It is designed for use in various board-to-board and wire-to-board interconnection systems, supporting a current of 3 Amps and voltage up to 350V.

The pin header is made with brass contacts plated in tin housed within a durable polyester housing which provides excellent mechanical stability once soldered to a PCB. Its tail pin length is 2.9 mm with a mating pin length of 6.75 mm, allowing strong and reliable electrical connections.

This connector is ideal for industrial, computer, medical, consumer electronics, telecommunications, and transportation applications including desktop PCs, servers, monitors, exchange stations, industrial equipment, and automotive safety systems. The header’s breakaway feature allows designers to customize the number of pins to suit specific application needs.

The product operates reliably in harsh environments with operating temperatures ranging from -55°C to 125°C. Its unshrouded design favors flexible layout and ease of assembly during manufacturing.

Supports 3 Amp current rating for reliable performance. Constructed with brass contacts plated with tin for enhanced durability. Housing made of high-quality polyester material ensuring mechanical stability. Compatible with wire-to-board connector systems for versatile applications.

Operates reliably in temperatures from -55°C up to 125°C. Includes breakaway design to allow size customization during PCB assembly. High pin retention force for secure mating and soldered mechanical stability.

This Molex C-Grid III Series pin header is a robust solution for demanding electronic assembly needs and is widely used across multiple industrial segments seeking reliable and customizable PCB interconnects.
