Nexperia N-Channel MOSFET 200 mA 60 V Enhancement 3-Pin SOT-23 BSS138AKAR

Free Delivery in India | Lowest Global Shipping Charges

Nexperia N-Channel MOSFET 200 mA 60 V Enhancement 3-Pin SOT-23 BSS138AKAR

Name: Nexperia N-Channel MOSFET 200 mA 60 V Enhancement 3-Pin SOT-23 BSS138AKAR
Brand: Nexperia
SKU: 205698
Price: 0.08 USD
Availability: InStock



Category MOSFET Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	3mm
Model	BSS138AKAR
Width	1.4mm
Mount Type	Surface
Series	BSS138AKA
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Automotive Standard	AEC-Q101
Channel Type	N
Maximum Continuous Drain Current Id	200mA
Maximum Drain Source Voltage Vds	60V
Maximum Drain Source Resistance Rds	4.5Ω
Channel Mode	Enhancement
Maximum Power Dissipation Pd	1.06W
Typical Gate Charge Qg @ Vgs	0.39nC
Maximum Gate Source Voltage Vgs	-20, +20V
Forward Voltage Vf	1.2V

Key Features

Enhanced performance with low maximum drain-source resistance of 4.5Ω.
Surface mount type designed for compact electronic applications.
Supports maximum power dissipation of 1.06 W.
Suitable for operating temperatures from -55°C to 150°C.
Typical gate charge of 0.39 nC at Vgs facilitates efficient switching.
Maximum gate-source voltage of ±20 V for reliable operation.
Complies with AEC-Q101 automotive standard for robustness.
Compact dimensions with length 3 mm, width 1.4 mm, and height 1 mm.

Product Description

Nexperia BSS138AKAR is a high-quality N-Channel MOSFET transistor designed for surface mounting in a compact 3-Pin SOT-23 package. It features a maximum continuous drain current of 200 mA and a maximum drain-source voltage rating of 60 V, supporting enhancement channel mode operation. The device exhibits a maximum drain-source resistance of 4.5Ω and a typical gate charge of 0.39 nC at gate-source voltage, enabling efficient switching in electronic circuits.

This MOSFET operates reliably across a wide temperature range from -55°C to 150°C, making it suitable for harsh industrial, automotive, and consumer electronics applications. Its compliance with the AEC-Q101 automotive standard underscores its durability and quality for automotive system integration.

The device’s compact dimensions (3 mm length, 1.4 mm width, 1 mm height) facilitate high-density PCB layouts and surface mount designs. Additionally, its maximum power dissipation rating of 1.06 W and gate-source voltage tolerance of ±20 V ensure stable performance under varying electrical conditions.

This transistor is commonly used in power management circuits, switching applications, signal amplification, and load switching in electronics manufacturing and automotive industries. Its small forward voltage drop of 1.2 V helps reduce power losses and improves energy efficiency.

Enhanced performance with low drain-source resistance. Compact SOT-23 surface mount package. Supports wide temperature range for industrial use. Compliant with automotive grade AEC-Q101 standard. Suitable for power management and switching applications.

Reliable operation with ±20 V gate-source voltage tolerance. Compact size enables high-density circuit design. Low forward voltage drop ensures energy efficiency.

This product is an ideal choice for industrial and automotive embedded electronics, laboratory instrumentation, manufacturing automation, and general-purpose discrete semiconductor uses. Explore the Electronics & Electricals section at EnvMart for comprehensive semiconductor and MOSFET components from top brands including Nexperia.
