Vishay 1-Element Bi-Directional TVS Diode Surface Mount SMC Package 1.5 kW Peak Pulse Power SMCJ70CA-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ70CA-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 113V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 77.8V |
| Maximum Reverse Stand-off Voltage Vwm | 70V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 13.3A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Bi-directional diode configuration protecting circuits from voltage transients.
- Surface mount type suitable for automated PCB assembly.
- Peak pulse power dissipation of 1.5 kW for robust surge protection.
- Minimum breakdown voltage of 77.8 V and maximum reverse stand-off voltage of 70 V.
- Clamping voltage maximum of 113 V to limit transient voltage spikes.
- Operating temperature range from -55°C to 150°C for extended reliability.
- High peak pulse current rating at 13.3 A supports high transient surge capacity.
- Low leakage current of 1 μA ensures minimal electrical loss during normal operation.
Product Description
Vishay SMCJ70CA-E3/57T is a single-element, bi-directional Transient Voltage Suppressor (TVS) diode designed for protection of sensitive electronic circuits against transient voltage spikes. Packaged in a surface mount SMC package, it provides efficient and reliable transient suppression with a peak pulse power rating of 1.5 kW.
This diode has a minimum breakdown voltage of 77.8 V, with a maximum reverse stand-off voltage of 70 V, making it suitable for protecting low voltage systems. The maximum clamping voltage of 113 V ensures that transient voltage spikes are clamped quickly to prevent damage.
It features a low maximum reverse leakage current of 1 μA, which reduces power loss and maintains circuit efficiency. The maximum peak pulse current rating of 13.3 A enables handling of high surge currents typically encountered during electrostatic discharges or lightning transients.
The device operates reliably across a wide temperature range from -55°C to 150°C, fulfilling automotive standard AEC-Q101 requirements, thus making it ideal for automotive and industrial electronics environments.
The compact SMC package dimensions are 7.11 mm (length), 6.22 mm (width), and 2.42 mm (height), which allows for space-efficient PCB layout and assembly using automated surface-mount technology.
Bi-directional single element configuration for protection of circuits against transient voltage surges. High peak pulse power dissipation capability of 1.5 kW for robust transient voltage handling. Low leakage current supports energy-efficient circuit operation.
Wide operating temperature range suitable for harsh environmental conditions. AEC-Q101 qualification ensures automotive industry compliance and reliability. Compact SMC surface mount package for optimized PCB utilization.
This Vishay TVS Diode is widely applicable in electronic circuits requiring ESD protection, surge suppression, industrial controls, automotive electronics, and power supply safeguards.
Explore more Transient Voltage Suppressors and electronic components to meet your circuit protection needs efficiently on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of the Vishay SMCJ70CA-E3/57T is 1.5 kW, providing robust surge protection.
The maximum clamping voltage for this diode is 113 V, which helps limit transient voltage spikes effectively.
This diode operates reliably within a temperature range of -55°C to 150°C, suitable for harsh environments.
The minimum breakdown voltage for the Vishay SMCJ70CA-E3/57T is 77.8 V, making it suitable for low voltage systems.
This model features a single element configuration, designed for bi-directional transient voltage suppression.
The dimensions of the SMC package are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
The maximum reverse leakage current is 1 μA, which ensures minimal electrical loss during normal operation.
This diode has a maximum peak pulse current rating of 13.3 A, enabling it to handle high surge currents effectively.
The Vishay SMCJ70CA-E3/57T complies with the automotive standard AEC-Q101, ensuring reliability in automotive applications.
This model is designed for surface mounting, making it suitable for automated PCB assembly.
This diode is widely applicable in electronic circuits requiring ESD protection, surge suppression, and power supply safeguards.
The package type of the Vishay SMCJ70CA-E3/57T is SMC, which allows for optimized PCB utilization.
