Vishay 1-Element Bi-Directional TVS Diode 600 W, 2-Pin Surface Mount DO-214AA SMB Package SMBJ24CA-E3/52

Vishay SMBJ24CA-E3/52 1-Element Bi-Directional TVS Diode offers transient voltage suppression with a peak pulse power dissipation of 600 W in a compact surface mount DO-214AA SMB package. Engineered for protection against voltage spikes and surges, it is suitable for use in industrial, automotive, communication, and consumer electronic circuits.

The diode features a single element in a bidirectional configuration providing symmetrical protection from transient voltage spikes in both directions. Its low clamping voltage of 38.9 V and minimum breakdown voltage of 26.7 V ensure effective suppression without compromising circuit performance.

Designed for use in environments with temperatures ranging from -55°C up to a maximum of 150°C, it ensures high reliability and durability. The device has a minimal reverse leakage current of 1μA which reduces power loss during normal operation.

Compliance with the automotive standard AEC-Q101 makes this diode suitable for stringent automotive applications where high reliability is mandatory. Additionally, its fast response time provides excellent clamping capability to protect sensitive semiconductor devices from damage.

The compact 2-pin surface mount DO-214AA package facilitates efficient PCB layout and high-density assembly in electronic devices. Its low resistance and incremental surge handling characteristics add to the robustness of the protection it provides.

Single diode configuration for effective bidirectional transient voltage suppression. Maximum peak power dissipation of 600 Watts ensures robust protection in electronic circuits. Minimum breakdown voltage of 26.7 V with clamping voltage of 38.9 V for surge protection.

Compact surface mount DO-214AA SMB package with 2 pins for easy PCB mounting. Wide operating temperature range from -55°C to 150°C. Electrostatic Discharge protection included to safeguard sensitive components. Automotive compliant to AEC-Q101 standard ensuring quality and durability.

Very low reverse leakage current of 1μA and peak pulse current of 15.4 A.

This device is ideal for protecting electronic circuits in industrial control, automotive, telecom, and power supply applications. It is part of Vishay’s TRANSZORB® series of transient voltage suppressors built for superior surge protection.
