onsemi Silicon Junction Switching Diode 4 A 600 V DO-201AD Through Hole MUR460RLG
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 5.3mm |
| Brand | onsemi |
| Height | 5.3mm |
| Length | 9.5mm |
| Model | MUR460RLG |
| Width | 5.3mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-201AD |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 110A |
| Maximum Forward Voltage Vf | 1.28V |
| Peak Reverse Recovery Time trr | 75ns |
| Maximum Forward Current If | 4A |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 600V |
| onsemi 600V 4A, Silicon Junction Diode, 2-Pin DO-201AD MUR460Brand | ON Semiconductor |
Key Features
- The diode has a through-hole mount type suitable for traditional PCB assembly.
- It offers a maximum forward voltage drop of 1.28 V for efficient rectification.
- Peak reverse recovery time is rated at 75 nanoseconds ensuring fast switching performance.
- Operating temperature ranges from -65°C to a maximum of 175°C for reliable performance in harsh conditions.
- The device features a 2-pin configuration with physical dimensions of 9.5mm length and 5.3mm diameter.
- Peak non-repetitive forward surge current capacity is 110 A for transient surge tolerance.
- The diode does not carry automotive or other specific industry certifications.
Product Description
onsemi MUR460RLG is a single silicon junction switching diode designed for use in power and electronic applications requiring a forward current rating of 4 A and a blocking voltage up to 600 V. Packaged in a DO-201AD through-hole mount case, this diode provides reliable rectification in industrial, laboratory, manufacturing, and consumer electronics circuits.
The diode's peak reverse recovery time of 75 ns and maximum forward voltage of 1.28 V makes it suitable for high-speed switching tasks, minimizing switching losses. It can operate safely in extreme ambient temperatures from -65°C to 175°C, enhancing its suitability for demanding environments including automotive and power supply circuits.
Physical dimensions include a 9.5 mm length and 5.3 mm diameter, ensuring compatibility with standard through-hole mounting on PCBs. It features a 2-pin configuration that simplifies installation and circuit integration.
This component does not have specific approvals or automotive certifications but meets general engineering standards for discrete semiconductors. Its peak non-repetitive forward surge current of 110 A supports transient load conditions without damage.
The diode is a single silicon junction type with excellent switching characteristics. Through-hole mount DO-201AD package ensures ease of use in prototyping and manufacturing. Wide operating temperature range supports use in industrial and commercial electronics.
Peak surge current capability protects during transient conditions. Compact physical dimensions enable use in space-constrained designs. Suitable for power rectification, switching, and freewheeling diode applications. Ideal for industrial, laboratory, and electronic manufacturing applications.
Explore the Electronics & Electricals semiconductor catalog for more Switching Diodes and related components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MUR460RLG diode has a maximum forward current rating of 4 A.
The peak reverse recovery time for the MUR460RLG is rated at 75 nanoseconds.
This model can handle a maximum blocking voltage of 600 V.
The diode has a length of 9.5 mm and a diameter of 5.3 mm.
The MUR460RLG operates within a temperature range of -65°C to 175°C.
It uses a through-hole mount type suitable for traditional PCB assembly.
The diode can withstand a peak non-repetitive forward surge current of 110 A.
The maximum forward voltage drop for the MUR460RLG is 1.28 V.
This diode features a 2-pin configuration.
It is packaged in a DO-201AD package type.
This diode is suitable for power rectification, switching, and freewheeling applications in industrial and electronic manufacturing.
The diode is manufactured in India.
