onsemi 1, 2.5 V Zener Diode, Single 500 mW 5% Voltage Regulator Surface Mount SOD-123 MMSZ5222BT1G

The onsemi MMSZ5222BT1G is a surface mount Zener diode designed for voltage regulation applications with a nominal Zener voltage of 2.5 V. It operates with a maximum power dissipation of 500 mW and features a single diode element in a compact 2-pin SOD-123 package, suitable for automated PCB assembly in industrial and electronic manufacturing contexts.

This diode exhibits a tolerance of ±5% on its Zener voltage, providing consistent voltage regulation performance. It supports a test current rating of 20 mA and maintains a maximum Zener impedance of 30 ohms, optimizing it for stable voltage clamping. The maximum reverse leakage current is limited to 100 microamperes, minimizing energy loss and ensuring efficiency in circuits.

With an operating temperature range extending from -55°C to 150°C, the MMSZ5222BT1G is reliable in a broad range of industrial, commercial, and laboratory environments. Its dimensions, measuring 3.86 mm in length and 1.35 mm in height, enable space-efficient design layouts for compact electronic assemblies.

The product complies with RoHS standards, reflecting environmentally conscious manufacturing. While this diode is not suitable for automotive-certified applications, it serves well in general semiconductor use cases, including power management, voltage clamping, and reference voltage stabilization in electronic devices.

Packaged in a surface mount SOD-123 case, the diode supports high-volume manufacturing and automated insertion processes, making it ideal for modern electronic component assembly lines.

Single diode configuration optimized for voltage regulation. Surface mount type with 2-pin SOD-123 package for PCB assembly. Voltage tolerance of ±5% ensures stable performance. Maximum reverse leakage current of 100 microamperes for minimal loss.

Operating temperature range from -55°C to 150°C for diverse environments. Test current rating of 20 mA for reliable diode operation. Maximum Zener impedance of 30 ohms for effective voltage stabilization. Dimensions: 3.86 mm length and 1.35 mm height for space-efficient design.

RoHS compliant ensuring environmentally safe manufacturing. Not certified for automotive standard applications. Explore more Zener Diodes and electronic components on EnvMart for reliable semiconductor solutions tailored to your industrial and design requirements.
