TDK Film Capacitor 150 nF 400V AC 1 kV DC Through Hole 2 Pin B32686A0154K000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 150 nF 400V AC 1 kV DC Through Hole 2 Pin B32686A0154K000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	Brazil
Brand	TDK
Height	25mm
Length	42mm
Model	B32686A0154K000
Width	14mm
Mount Type	Through Hole
Series	B32686
Maximum Operating Temperature	110°C
Capacitance	150nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	400V ac
Rated DC Voltage	1kV dc
Lead Pitch	37.5mm
Lead Diameter	1mm

Key Features

This capacitor features a 150 nF capacitance suitable for high voltage applications.
Rated for 400V alternating current and 1 kV direct current operation.
Through hole mount type with 2 pins providing secure PCB attachment.
Compact dimensions of 42mm length, 25mm height, and 14mm width enable easy integration.
Maximum operating temperature up to 110°C allows use in demanding environments.
Constructed with self-healing polypropylene film designed for pulse strength and reliability.
Meets RoHS and UL standards ensuring quality and safety compliance.
Lead pitch is 37.5mm with 1mm lead diameter for compatibility with standard circuit boards.

Product Description

TDK B32686A0154K000 Film Capacitor is a high-performance electronic component designed for reliable operation in power and signal conditioning applications. This capacitor provides a capacitance of 150 nF and supports high voltage ratings of 400V AC and 1 kV DC, making it suitable for electronic ballasts, snubber circuits, smoothing filters, switch mode power supplies, and other industrial electronics requiring robust capacitance and voltage endurance.

This through hole mount capacitor has a lead pitch of 37.5mm and two pins, providing mechanical stability and ease of insertion into printed circuit boards. Its polypropylene film construction offers excellent pulse strength and self-healing properties, ensuring high durability and contact reliability in challenging electrical environments.

With maximum operating temperature of 110°C and compliance with RoHS and UL standards, this capacitor meets industrial quality and safety requirements, suitable for use in construction, manufacturing, laboratory instrumentation, and HVAC controls.

Key physical dimensions include a length of 42mm, height of 25mm, and width of 14mm, with leads having a diameter of 1mm. The product is manufactured in Brazil and designed to support demanding industrial and commercial applications.

This film capacitor delivers high pulse strength and contact reliability. Rated for both DC (1 kV) and AC (400V) applications ensuring versatile use. Compact through hole design facilitates straightforward PCB mounting. Polypropylene film materials provide self-healing and long-term durability.

Approved under RoHS and UL standards for safety and environmental compliance. Designed for use in electronic ballasts, snubber circuits, smoothing, and switch mode power supplies. Operates reliably at up to 110°C maximum temperature conditions.

Comes with 37.5mm lead pitch and 2 pins for mechanical stability.

This capacitor is a reliable choice for engineers and professionals working in electronics manufacturing, PCB design, industrial automation, and power supply systems. Browse more Film Capacitors and other electronic components at EnvMart.
