Phoenix Contact FP 1.27/40-FWL Series Right Angle Cable PCB Socket, 40-Contact, 2 Row, 1.27 mm Pitch IDC 1714908

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact FP 1.27/40-FWL Series Right Angle Cable PCB Socket, 40-Contact, 2 Row, 1.27 mm Pitch IDC 1714908

Name: Phoenix Contact FP 1.27/40-FWL Series Right Angle Cable PCB Socket, 40-Contact, 2 Row, 1.27 mm Pitch IDC 1714908
Brand: PHOENIX CONTACT
SKU: 161654
Price: 10.83 USD
Availability: InStock



Category PCB Socket Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Czech Republic
Voltage	500V
Brand	Phoenix Contact
Orientation	Right Angle
Current	1.2A
Model	1714908
Mount Type	Cable
Housing Material	Liquid Crystal Polymer
Contact Material	Copper
Series	FP 1.27/40-FWL
Termination Type	IDC
Maximum Operating Temperature	125°C
Sub Type	Female Connector
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	40
Contact Gender	Female
Connector System	Board-to-Board
Stacking Height	8mm
IDC female connector, Nominal current at 20 °C	1.2 A, Test voltage: 500 V AC, number of positions: 40, pitch: 1.27 mm, colour: black, contact surface: Gold

Key Features

The connector supports a nominal current of 1.2 A at 20 °C temperature.
Designed for use with cable mounting in a right-angle orientation.
Housing is constructed from Liquid Crystal Polymer, ensuring durability and performance.
Contacts are made of copper with gold plating for enhanced conductivity and corrosion resistance.
Operating voltage rating up to 500 V and a stacking height of 8 mm to fit compact assemblies.
Suitable for board-to-board connector systems and industrial electronic applications.
Operational temperature range from -55 °C to 125 °C supports harsh environments.
Manufactured in Czech Republic to ensure quality and industry compliance.

Product Description

Phoenix Contact 1714908 FP 1.27/40-FWL Series Right Angle Cable PCB Socket is a high-quality IDC female connector designed for industrial and electronic applications requiring reliable electrical connections. Featuring 40 contacts arranged in 2 rows with a precise 1.27 mm pitch, this connector supports nominal current up to 1.2 A at 20 °C and test voltage of 500 V AC. The black Liquid Crystal Polymer housing provides excellent mechanical stability and durability.

This right-angle cable connector boasts gold-plated copper contacts to ensure optimal conductivity and resistance to corrosion, making it suitable for demanding environments. Its stacking height of 8 mm allows compact placement within electronic assemblies, supporting board-to-board connection systems.

Designed to operate reliably from -55 °C to 125 °C, this PCB socket fits a wide range of industrial, manufacturing, and electronic equipment including power connectors, telecommunications, and automation systems.

The connector provides secure IDC termination for cable mounting. Its gold-plated copper contacts facilitate reliable signal transmission and long-term durability. Compact design with right-angle orientation enables efficient PCB layout optimization.

Suitable for industrial and laboratory electronic assemblies requiring robust connections. Operates safely within a wide temperature range to handle harsh conditions. Manufactured in Czech Republic with high quality standards for electronic components.

Ideal for applications involving power and signal transmissions with high current and voltage requirements.

This FP 1.27/40-FWL Series PCB Socket connector from Phoenix Contact enables efficient cable-to-board interfacing for electronic manufacturing, laboratory instrumentation, and industrial automation. It is a reliable choice for engineers and technicians seeking a durable and precision-engineered IDC right-angle cable socket with excellent electrical and mechanical performance.
