Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header, 18 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 39-30-1180

Molex 39-30-1180 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-quality power connector designed for PCB mounting applications. This 18-contact connector features a 4.2 mm pitch and a two-row arrangement, making it suitable for compact and reliable electronic assemblies.

The connector housing is made of durable nylon material with a scoop-proof design that prevents damage to the pin terminals during mating. Fully isolated terminals provide protection against debris, arcing, and mishandling damage, ensuring long-term reliability.

Its positive locking mechanism secures the connection firmly, preventing accidental disconnections caused by vibration or shock. An audible click confirms proper mating. The connector uses brass contacts with tin plating to ensure good electrical conductivity and corrosion resistance, and the contacts have a solder termination type with a 3.5 mm tail pin length suitable for through-hole PCB mounting.

This PCB header is rated for a maximum current of 6A per circuit and supports an operating voltage of up to 600V. It operates within a temperature range from -40°C to 105°C, suitable for demanding industrial environments. The connector's right-angle orientation accommodates PCB layouts requiring space-saving designs.

Mini-Fit Jr Series connectors are widely used in applications including consumer white goods, office equipment, industrial automation, networking servers, routers, and switches due to their robustness and reliable performance in high current and high-density wire-to-board interconnect situations.

Supports a maximum current of 6A per contact for high power needs. Constructed with a nylon housing that is scoop-proof to prevent contact damage. Features fully isolated terminals to protect against debris and arcing. Includes a positive locking mechanism and audible mating click for secure connections.

Contacts are brass with tin plating and a solder termination type with 3.5 mm tail pin length. Operates reliably between -40°C and 105°C ambient temperatures. Designed as a two-row, 18-contact system with a 4.2 mm row pitch for compact installation.

Suitable for wire-to-board connections using through-hole mounting technology. This product is manufactured in Mexico and is supplied new with high quality standards. Explore more PCB Headers and power connectors from Molex and similar brands on EnvMart for industrial and commercial electronic applications.
