Molex C-Grid III Series Straight Through Hole PCB Header, 16 Contact, 2.54 mm Pitch, 2 Row, Shrouded 90130-1116
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features 16 male contacts spaced at 2.54 mm pitch for precise PCB connectivity.
- Constructed with polyester housing offering durability and resistance.
- Brass contact material plated with tin ensures reliable electrical performance.
- Rated for 3A current and 350V voltage handling capacity.
- Designed for through-hole mounting with a straight orientation and shrouded connector system.
- Suitable for operating temperatures ranging from -55°C to 125°C.
- Termination by solder method with a tail pin length of 2.9 mm and mating pin length of 6.75 mm.
- No specific standards or approvals are indicated for this model.
Product Description
The Molex 90130-1116 is a C-Grid III Series Straight Through Hole PCB Header designed for electronic and electrical applications requiring reliable wire-to-board connections. Featuring 16 male contacts with a precise 2.54 mm pitch and arranged in 2 rows, this header ensures consistent and secure connectivity.
Its polyester housing provides strong insulation and mechanical strength, while the brass contacts plated with tin guarantee optimal electrical conductivity and corrosion resistance. Rated for a continuous current of 3A and maximum voltage of 350V, this connector is suitable for demanding industrial environments.
The through-hole mount design with straight orientation facilitates easy PCB assembly, and the shrouded configuration enhances protection from accidental disconnections and environmental factors. Operating temperature ranges from -55°C up to 125°C, allowing use in a wide range of industrial, laboratory, and manufacturing settings.
Termination is soldered with tail pin length at 2.9 mm, and the mating pin length of 6.75 mm ensures proper engagement with mating connectors. This product supports the C-Grid III locking header system, commonly used in electronic manufacturing and prototyping.
16 male contacts providing reliable electrical connectivity. Polyester housing offering mechanical strength and insulation. Brass contacts with tin plating for corrosion resistance. Current rating of 3A and voltage rating of 350V.
Through hole mount with straight orientation and shrouded design. Solder termination type with detailed pin lengths for secure fit. Operating temperature range from -55°C to 125°C. No specific standards or approvals provided.
Ideal for electronics manufacture, assembly, and repair.
This PCB Header is suitable for use in various environments including industrial electronics production, laboratory equipment assembly, and commercial electronics design. It supports secure and efficient PCB connection requirements with reliable performance.
Explore more Molex C-Grid III Series connectors and related electronic components to build robust circuit assemblies with confidence at EnvMart.
