Nexperia Resistor-Equipped NPN Transistor 100 mA, 50 V, 3-Pin DFN1412D-3 PDTC143EQC-QZ

The Nexperia PDTC143EQC-QZ is a resistor-equipped NPN bipolar transistor designed for efficient switching in electronic circuits. This device integrates resistors within an ultra-small DFN1412D-3 plastic package featuring side-wettable flanks, enabling automated optical inspection and facilitating surface mount assembly techniques.

It supports a maximum DC collector current of 100 mA and collector-emitter voltage of 50 V, making it suitable for controlling loads and switching tasks in digital applications. The transistor offers a minimum DC current gain of 30, with a transition frequency reaching up to 230 MHz, ensuring fast switching capabilities in demanding environments.

Its operating temperature range extends from -55°C to 150°C, granting versatility across industrial, automotive, and commercial electronics use cases. The product meets RoHS compliance and adheres to the automotive AEC-Q101 standard, confirming its quality and reliability in safety-critical applications.

The integrated resistor design reduces the required external component count, simplifying schematic layouts and decreasing pick-and-place costs in mass production. This transistor is well-suited for controlling IC inputs and switching loads in tightly-packed printed circuit boards of modern electronic devices.

Compact 3-pin DFN1412D-3 surface mount package for space-saving designs. Integrated resistors streamline circuit design and reduce components. Maximum collector current of 100 mA suitable for various switching applications.

Wide temperature range from -55°C to 150°C for harsh environments. High-frequency switching capabilities up to 230 MHz. Automotive grade AEC-Q101 certification ensures reliability in automotive electronics. RoHS compliant, supporting environmental standards.

Ideal for digital switching and controlling IC inputs in complex circuits.

This NPN resistor-equipped transistor from Nexperia is an efficient and reliable component choice for electronic engineers focusing on compact, cost-effective PCB designs in industrial, automotive, and consumer electronics sectors. Explore additional Nexperia Bipolar Transistors and related semiconductor products to meet comprehensive design requirements.
