Samtec T1M Series Vertical Surface PCB Header, 3 Contacts, 1 mm Pitch, Shrouded, Wire-to-Board, T1M-03-F-SH-L
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 3.3A |
| Model | T1M-03-F-SH-L |
| Mount Type | Surface |
| Housing Material | Natural LCP |
| Contact Material | Phosphor Bronze |
| Series | T1M |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -10°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Silver, Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Shrouded vertical PCB header with surface mount design.
- Features 3 phosphor bronze contacts with silver and tin plating.
- Supports a current rating of up to 3.3A per contact.
- Pitch of 1 mm for dense and miniature PCB layouts.
- Natural LCP housing material for reliable durability.
- Operating voltage up to 250V.
- One row configuration, male contact gender.
- Positive latch mechanism for secure connection.
Product Description
Samtec T1M-03-F-SH-L PCB Header is a high-quality vertical surface mount connector, designed for professional electronic applications requiring reliable wire-to-board connectivity in compact circuits. With a pitch of 1 mm and 3 discrete contacts, it is ideal for miniature PCB layouts where space efficiency and mechanical strength are essential.
The header is shrouded, ensuring proper mating and alignment with corresponding connectors, reducing the risk of misconnection or physical stress. It uses phosphor bronze contacts plated with silver and tin, providing excellent electrical conductivity and corrosion resistance. The housing material is natural Liquid Crystal Polymer (LCP), selected for its mechanical and thermal stability, ensuring long-lasting performance even in challenging industrial environments.
Shrouded vertical PCB header with surface mount design. Features 3 phosphor bronze contacts with silver and tin plating. Supports a current rating of up to 3.3A per contact. Pitch of 1 mm for dense and miniature PCB layouts.
Natural LCP housing material for reliable durability. Operating voltage up to 250V. One row configuration, male contact gender. Positive latch mechanism for secure connection. Wire-to-board connector system enhancing assembly convenience.
Termination type is solder for robust PCB mounting.
Typical applications include consumer electronics, medical devices, industrial control boards, automotive modules, and instrumentation where high-density, reliable surface-mounted connectors are required. Operating temperature ranges from -10°C to 85°C, making this header suitable for varied environments.
As part of the Samtec T1M Series, this product offers consistent quality and adherence to rigorous international standards for connector performance, but no explicit certifications are claimed unless specified on the official datasheet. Its secure positive latch supports safe assembly and maintenance operations within professional electronic assembly lines.
Explore more PCB Headers, connectors, and related solutions by Samtec in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of up to 3.3A per contact.
The maximum operating voltage for this header is 250V.
It features a surface mount design, suitable for compact PCB layouts.
The pitch size of the contacts is 1 mm, allowing for dense PCB layouts.
The contacts are made of phosphor bronze with silver and tin plating, while the housing is constructed from natural Liquid Crystal Polymer (LCP).
The operating temperature range is from -10°C to 85°C, making it suitable for various environments.
This model features 3 contacts arranged in a single row configuration.
It uses a solder termination type for robust PCB mounting.
This header is shrouded, which helps ensure proper mating and alignment with corresponding connectors.
The contact gender of this model is male.
Typical applications include consumer electronics, medical devices, industrial control boards, automotive modules, and instrumentation.
The country of origin for this product is India.
