TDK Through Hole EMC Filter 2A 250V ac/dc 60Hz Pin Termination Single Phase B84110A0000A020

Free Delivery in India | Lowest Global Shipping Charges

TDK Through Hole EMC Filter 2A 250V ac/dc 60Hz Pin Termination Single Phase B84110A0000A020



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	23mm
Length	56mm
Model	B84110A0000A020
Depth	30mm
Mount Type	Through Hole
Operating Frequency	60Hz
Series	B84110-A
Maximum Operating Temperature	100°C
Capacitance	4700pF
Minimum Operating Temperature	-25°C
Maximum Current	2A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	2mH
Standards/Approvals	UL1283
Termination Style	Pin
Applications include	medium-performance SMPSUs, data systems, gambling machines

Key Features

The filter offers a capacitance of 4700pF for effective noise suppression.
It has an inductance of 2mH and a leakage current of 369μA.
Designed for through hole mounting with pin termination style.
Operates reliably in temperatures ranging from -25°C to 100°C.
Complies with UL1283 safety standards for electromagnetic filters.
Compact size with dimensions 56mm length, 23mm height, and 30mm depth.
Suitable for medium-performance switch mode power supplies, data systems, and gambling machines.
Constructed with a plastic housing for durability.

Product Description

TDK B84110A0000A020 Through Hole EMC Filter is a compact, reliable component designed to suppress electromagnetic interference in single-phase electrical systems. Rated for a maximum current of 2A and voltage up to 250V ac/dc, this filter operates efficiently at a frequency of 60Hz, ensuring stable performance across various applications.

The filter features a capacitance of 4700pF and inductance of 2mH, providing effective attenuation of noise signals. Its leakage current is limited to 369μA, maintaining energy efficiency and safety in electronic circuits.

This filter employs a through hole mount type with pin terminations facilitating secure PCB mounting, suitable for integration into medium-performance switch mode power supplies (SMPSUs), data systems, and gambling machines. The plastic housing offers robust protection while maintaining a compact form factor with dimensions 56mm (length) x 23mm (height) x 30mm (depth).

Operating temperature range is from -25°C to 100°C, making it suitable for varied industrial and commercial environments. It complies with UL1283 standards, ensuring product safety and quality reliability.

The filter offers a capacitance of 4700pF for effective noise suppression. It has an inductance of 2mH and a leakage current of 369μA. Designed for through hole mounting with pin termination style. Operates reliably in temperatures ranging from -25°C to 100°C.

Complies with UL1283 safety standards for electromagnetic filters. Compact size with dimensions 56mm length, 23mm height, and 30mm depth. Suitable for medium-performance switch mode power supplies, data systems, and gambling machines.

Constructed with a plastic housing for durability. It is a critical component for enhancing electromagnetic compatibility (EMC) and reducing interference in sensitive electronics.
