TDK Unshielded Surface Mount Common Mode Choke with Ferrite Core 51 μH ±30 % 800 mA Idc B82793S0513N201
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 4.8mm |
| Length | 7.1mm |
| Model | B82793S0513N201 |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | B82793 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 51μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 800mA |
| Pin Count | 2 |
| Maximum DC Resistance | 140mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Solder |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Complies with automotive standard AEC-Q200 for robust performance.
- Tape and reel packaging facilitates high-efficiency automated assembly.
- Flame retardant moulded case rated UL 94 V-0 enhances safety.
- Suitable for industrial applications requiring suppression of asymmetric and symmetric interference.
- Wirewound inductor construction with ferrite core ensuring reliable operation.
- RoHS compliant and lead-free tinned solder terminals for environmental safety.
- Operating temperature range from -40°C to 125°C ensures durable usage.
Product Description
TDK B82793S0513N201 is an unshielded surface mount common mode choke featuring a ferrite core with an inductance of 51 μH ±30 % and a maximum DC current of 800 mA. This component is designed to suppress electromagnetic interference (EMI) in industrial and automotive electronic circuits.
The choke is packaged in tape and reel format, enabling efficient insertion into automated production lines. Its dimensions of 7.1 mm length, 4.8 mm height, and 6 mm depth make it suitable for compact PCB layouts where space efficiency is critical.
This inductor is constructed with a wirewound design and a ferrite core, providing effective interference suppression across a broad frequency range. The product meets the automotive standard AEC-Q200, ensuring reliability under demanding conditions.
The moulded case is flame retardant compliant with UL 94 V-0, complementing the lead-free tinned solder terminals that promote environmentally friendly manufacturing practices. Operating temperature ranges from -40°C to 125°C allow for stable performance in harsh environments.
Typical applications include industrial electronics, automotive systems, and any electronic equipment requiring reduction of symmetrical and asymmetrical interference to improve EMC performance.
Complies with automotive standard AEC-Q200 for robust performance. Tape and reel packaging facilitates high-efficiency automated assembly. Compact dimensions: 7.1 mm length, 4.8 mm height, and 6 mm depth. Flame retardant moulded case rated UL 94 V-0 enhances safety.
Suitable for industrial applications requiring suppression of asymmetric and symmetric interference. Wirewound inductor construction with ferrite core ensuring reliable operation. RoHS compliant and lead-free tinned solder terminals for environmental safety.
Operating temperature range from -40°C to 125°C ensures durable usage. Browse the Surface Mount Inductors category on EnvMart for more reliable and high-quality passive components from top brands like TDK.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance of 51 μH with a tolerance of ±30%.
The maximum DC current for this unit is 800 mA.
It has dimensions of 7.1 mm in length, 4.8 mm in height, and 6 mm in depth, making it suitable for compact PCB layouts.
The operating temperature range is from -40°C to 125°C, allowing for stable performance in harsh environments.
Yes, it complies with the automotive standard AEC-Q200 and is RoHS compliant.
It is packaged in tape and reel format, which facilitates high-efficiency automated assembly.
The inductor is constructed with a ferrite core, which is effective for interference suppression.
This model features a solder termination style, suitable for surface mount applications.
The maximum DC resistance is 140 mΩ, which contributes to its performance in electronic circuits.
It is suitable for industrial electronics and automotive systems, particularly for reducing symmetrical and asymmetrical interference.
It features a wirewound inductor construction, ensuring reliable operation in various applications.
The moulded case is flame retardant and compliant with UL 94 V-0, enhancing safety during use.
