Samtec Pin Header 4 Contacts 2 mm Pitch 2 Row Through Hole Unshrouded TMM-102-03-L-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec Pin Header 4 Contacts 2 mm Pitch 2 Row Through Hole Unshrouded TMM-102-03-L-D

Name: Samtec Pin Header 4 Contacts 2 mm Pitch 2 Row Through Hole Unshrouded TMM-102-03-L-D
Brand: Samtec
SKU: 99084
Price: 0.63 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	281V
Brand	Samtec
Orientation	Straight
Current	3A
Model	TMM-102-03-L-D
Mount Type	Through Hole
Special Features	FleXYZ™ provides design flexibility in all three axes up to four rows wide and 200 pins
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TMM
Termination	Through-hole, surface mount
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.7mm
Mating Pin Length	4mm
Contact System	.020" (0.50 mm) square post

Key Features

Designed for wire-to-board connector systems with male contacts.
Features phosphor bronze contact material with gold plating for enhanced conductivity.
Supports a current rating of 3A and voltage up to 281V.
Constructed with a liquid crystal polymer housing for durability.
Operates reliably between -55°C and 125°C.
Tail pin length is 2.7 mm and mating pin length is 4 mm.
Offers design flexibility with FleXYZ™ technology allowing multi-axis alignment.
Termination is suitable for soldering, enabling secure and stable connections.

Product Description

Samtec TMM-102-03-L-D is a high-quality pin header designed for electronic circuit board connections, featuring 4 contacts arranged in 2 rows with a 2 mm pitch spacing. This unshrouded, straight orientation through-hole connector is engineered to meet demanding electrical and mechanical requirements in industrial and commercial electronic assemblies.

Constructed with a housing made of liquid crystal polymer, the connector offers excellent durability and resistance to thermal stress, operating reliably in a temperature range from -55°C up to 125°C. The contacts are crafted from phosphor bronze and plated with gold to provide superior conductivity and corrosion resistance.

This pin header supports a current rating of 3 amperes and a voltage up to 281 volts, making it suitable for a range of power and signal applications. It features a male contact type with tail pin length of 2.7 mm and mating pin length of 4 mm to facilitate secure solder connections on PCBs.

The product includes FleXYZ™ technology, offering design flexibility in all three axes with options for configurations up to four rows wide and 200 pins, allowing for customized layouts in complex electronic assemblies. Termination styles include through-hole and surface mount, making this header adaptable to various manufacturing processes.

Designed for wire-to-board connector interfaces requiring robust and reliable electrical contacts. Liquid crystal polymer housing enhances mechanical stability and thermal endurance. Gold-plated phosphor bronze contacts ensure high conductivity and long-term performance.

Suitable for industrial, laboratory, and commercial electronic device manufacturing. Supports automated soldering techniques with precise tail pin and mating pin dimensions.

This Samtec pin header is ideal for applications in electronic component manufacturing, PCB assembly lines, and equipment requiring flexible and reliable interconnection solutions. Explore a comprehensive range of electronic components and connectors in the EnvMart Electronics & Electricals category for your specialized requirements.
