Samtec Pin Header 36 Contacts 2.54 mm Pitch Vertical Surface Mount Unshrouded TSM-136-01-TM-SV

Samtec TSM-136-01-TM-SV is a high-quality vertical surface mount pin header designed with 36 contacts at a 2.54 mm pitch to support reliable board-to-board connections. Equipped with an unshrouded female interface, this connector is ideal for applications requiring straightforward access and durability on densely populated PCBs.

The housing is made from liquid crystal polymer, delivering superior mechanical strength and heat resistance, complemented by phosphor bronze contacts with gold or tin plating that ensure excellent electrical conductivity and corrosion resistance. It supports a broad temperature range from -55°C to +125°C, making it suitable for demanding industrial, electronic, and commercial environments.

The single row, vertical orientation optimizes space efficiency on printed circuit boards while providing consistent connectivity. This pin header's 475 V voltage rating makes it compatible with many low- to mid-voltage electronic systems requiring robust termination methods. The solder termination type offers strong mechanical retention and electrical performance.

Unshrouded vertical surface mount connector, enabling direct board-to-board interfacing. Housing material crafted from liquid crystal polymer for durability and heat resistance. Phosphor bronze contact material plated with gold or tin ensures reliable conductance.

Wide operating temperature range from -55°C up to 125°C to function in harsh environments. Voltage rating up to 475 V accommodating electronic component demands. Single row with 36 contacts spaced at 2.54 mm pitch for precise alignment and signal integrity.

Termination by solder type ensures secure electrical and mechanical connections.

This pin header is widely used in industrial electronics, instrumentation, communications equipment, and PCB manufacturing where dependable board interconnection is demanded. The product’s robust design supports high-reliability applications in manufacturing, test equipment, laboratory instrumentation, and commercial electronics.

Discover more quality PCB connectors in the Electronics Components category at EnvMart. Browse our extensive catalog for diverse connector solutions from trusted manufacturers.

Explore more products in our PCB Pin Header category.
