Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 16-Contact, 2 Row, 2.54 mm Pitch 61001621821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Connector System | Board-to-Board |
Key Features
- Features a 2 row, 16-contact configuration for board-to-board connection.
- Surface mount type with straight orientation suitable for SMT applications.
- Constructed of copper alloy contacts with gold plating for reliable conductivity.
- Has a PA9T insulator with UL94 V-0 flammability rating ensuring safety.
- Durability rated for 25 mating cycles providing long-lasting performance.
- Operates within a wide temperature range from -40°C to 125°C.
- Capable of handling up to 3A current at 500V voltage rating.
- Designed specifically for industrial, electronic, and PCB assembly use.
Product Description
Wurth Elektronik 61001621821 WR-PHD Series Straight Surface PCB Socket is a precision-engineered board-to-board connector designed for high-performance electronic applications. This 16-contact socket features a 2.54 mm pitch across two rows, offering stable and reliable connectivity in industrial and electronic assembly scenarios. It is a surface mount component with a straight orientation, ensuring easy integration with SMT PCB designs.
The socket contacts are made from copper alloy with gold plating, providing excellent conductivity and corrosion resistance. The PA9T insulator material carries an UL94 V-0 flammability rating, which ensures compliance with safety standards. This connector is highly durable, rated for up to 25 mating cycles, making it suitable for repeated connections in testing and maintenance environments.
Operating temperature ranges from -40°C to 125°C, supporting both low and high-temperature industrial environments. The connector is rated for 3A current and 500V voltage, meeting the requirements for a wide variety of electronic devices and industrial equipment. The product is RoHS compliant and is manufactured in Taiwan, Province Of China.
Features a 2 row, 16-contact configuration for board-to-board connection. Surface mount type with straight orientation suitable for SMT applications. Constructed of copper alloy contacts with gold plating for reliable conductivity.
Has a PA9T insulator with UL94 V-0 flammability rating ensuring safety. Durability rated for 25 mating cycles providing long-lasting performance. Operates within a wide temperature range from -40°C to 125°C. Capable of handling up to 3A current at 500V voltage rating.
Designed specifically for industrial, electronic, and PCB assembly use. Manufactured in Taiwan, Province Of China.
This Wurth Elektronik WR-PHD series PCB socket is essential for industrial electronics, laboratory prototypes, manufacturing equipment, and construction machinery PCB assemblies that require stable, safe, and long-lasting connector solutions. EnvMart offers this high-quality component for precision engineering and electronics design projects.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts in this PCB socket have a pitch of 2.54 mm.
This model is capable of handling up to 3A of current.
The voltage rating for this PCB socket is 500V.
It operates within a temperature range from -40°C to 125°C.
This connector features a total of 16 contacts.
This PCB socket uses a surface mount type for installation.
The contacts are constructed from copper alloy with gold plating.
The durability of this socket is rated for up to 25 mating cycles.
The insulator material is PA9T, which has a UL94 V-0 flammability rating.
This product is manufactured in Taiwan, Province Of China.
It is designed specifically for industrial, electronic, and PCB assembly use.
This model has a straight orientation suitable for SMT applications.
