STMicroelectronics 1-Element Bi-Directional TVS Diode 600W 2-Pin DO-15 BZW06-15B
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.53mm |
| Brand | STMicroelectronics |
| Height | 3.53mm |
| Length | 6.75mm |
| Model | BZW06-15B |
| Width | 3.53mm |
| Mount Type | Through Hole |
| Series | BZW06 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-15 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 32.5V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 17.1V |
| Maximum Reverse Stand-off Voltage Vwm | 15.3V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 123A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- This TVS diode provides bidirectional transient voltage suppression for enhanced circuit protection.
- It supports a minimum breakdown voltage of 17.1V ensuring reliable clamp during voltage spikes.
- The package dimensions are compact with a length of 6.75mm, diameter and width of 3.53mm, suitable for space-constrained designs.
- Rated for operation from -65°C up to 175°C, making it suitable for harsh environments.
- It features a maximum peak pulse current of 123A and a clamping voltage of 32.5V to safely absorb transient surges.
- The device exhibits minimal reverse leakage current of 1μA, improving energy efficiency.
- Its single-element configuration simplifies protection design in sensitive electronics.
- No automotive standards compliance, focusing on general industrial and commercial uses.
Product Description
STMicroelectronics BZW06-15B is a 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed to protect sensitive electronic components from voltage spikes and transient surges. This diode has a robust peak pulse power dissipation of 600W and is contained in a 2-pin DO-15 through-hole mounting package, making it widely compatible for PCB assembly in diverse electronic circuits.
With a minimum breakdown voltage of 17.1V and maximum reverse stand-off voltage of 15.3V, it ensures effective clamping of voltage spikes with a clamping voltage of 32.5V. The device can handle a peak pulse current of up to 123A, ensuring reliable protection under harsh transient conditions.
It operates within a wide temperature range from -65°C to 175°C, suitable for industrial, HVAC, manufacturing, and power supply applications. Its low leakage current of 1μA helps maintain circuit efficiency and longevity. The compact size (length 6.75mm, diameter and width 3.53mm) facilitates integration in space-limited electronic designs.
This TVS diode is ideal for transient voltage protection in electronic components, power supplies, and other semiconductor devices, enhancing system robustness against unexpected voltage surges caused by switching, lightning, or electrostatic discharge.
This diode uses a single-element configuration optimized for bi-directional protection. Compact DO-15 axial package allows easy through-hole mounting on PCB boards. Wide operating temperature range supports demanding environmental conditions.
Low reverse leakage current improves energy efficiency and device reliability. 600W peak pulse power handling with 123A surge current rating ensures transient tolerance. Suitable for industrial electronics, power connectors, semiconductors, and discrete components protection.
STMicroelectronics quality ensures high reliability in electronic assemblies. Consider STMicroelectronics products for trusted transient voltage suppression components available on EnvMart, enhancing your circuit protection and reliability.
Explore more products in our Discrete Semiconductor category.
