Nexperia 100 mA NPN Bipolar Transistor 45 V 3-Pin SOT-23 BCX70H,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 100 mA NPN Bipolar Transistor 45 V 3-Pin SOT-23 BCX70H,215

Name: Nexperia 100 mA NPN Bipolar Transistor 45 V 3-Pin SOT-23 BCX70H,215
Brand: Nexperia
SKU: 189638
Price: 0.05 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BCX70H,215
Width	1.4mm
Mount Type	Surface
Series	BCX70
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	45V
Minimum DC Current Gain hFE	40
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	45V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Single
Maximum Transition Frequency ft	250MHz
ROHM Transistor, 100 mA NPN, 45 V, 3-Pin SOT-23Brand	ROHM

Key Features

This transistor is configured as a single NPN transistor suitable for general purpose applications.
It operates at a maximum power dissipation of 250 mW with a maximum transition frequency of 250 MHz.
It features a minimum DC current gain of 40 and supports surface mount technology.
The device complies with RoHS standards and automotive standard AEC-Q101.
Designed for operating temperatures ranging from -65°C to 150°C for robust performance.

Product Description

Nexperia BCX70H,215 bipolar transistor is a small signal NPN transistor designed for electronic circuit applications that require switching or amplification of low currents. With a maximum DC collector current of 100 mA and maximum collector emitter voltage of 45 V, this transistor ensures reliable performance in demanding conditions.

Housed in a compact 3-pin SOT-23 surface mount package, it provides ease of integration on modern printed circuit boards. Featuring a minimum DC current gain of 40 and a high maximum transition frequency of 250 MHz, the device allows efficient signal processing in high-frequency circuits.

Power dissipation capability of 250 mW enables stable operation under moderate loads. It is compliant with RoHS standards ensuring environmental safety and meets the automotive standard AEC-Q101, making it suitable for automotive electronics and industrial applications.

It operates over a wide temperature range from -65°C to 150°C, suitable for harsh environments. The compact dimensions of 3 mm length, 1.4 mm width, and 1.1 mm height further enhance its utility in space-constrained designs.

This transistor is configured as a single NPN device suitable for general purpose amplification and switching. The 3-pin SOT-23 package supports surface mounting for automated assembly processes. Maximum collector current of 100 mA and voltage rating of 45 V support a variety of circuit demands.

Compliance with RoHS and automotive standards ensures quality and reliability. Operating temperature range from -65°C to 150°C supports use in industrial and automotive environments.

This transistor finds applications in industrial electronics, automotive systems, consumer electronics, and communication equipment. Its compact form factor and electrical characteristics make it ideal for small signal amplification and switching circuits.
