Wurth Elektronik WR-FPC 1 mm Pitch 4 Way Horizontal Female FPC Connector, Solder 686104148922
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 100, 100V ac |
| Brand | Wurth Elektronik |
| Orientation | Horizontal |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Phosphor Bronze |
| Series | WR-FPC |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | FPC |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- This FPC connector features a 1 mm pitch and 4 contact positions for high-density connection.
- It has a horizontal female connector design with bottom contacts.
- The connector utilizes a flip-lock hinged actuator providing a secure Zero Insertion Force (ZIF) connection.
- Constructed with phosphor bronze contacts plated with tin over nickel and a polyamide housing.
- Supports operating voltages up to 100 V AC and current rating of 1A.
- Operates reliably in temperatures from -40 °C to 105 °C.
- Designed for solder surface mount mounting on PCBs with a single row of contacts.
- Ideal for applications such as small displays and keyboard connections in miniaturized electronics.
Product Description
Wurth Elektronik 686104148922 WR-FPC 1 mm Pitch 4 Way Horizontal Female FPC Connector is a low-profile, space-saving SMT ZIF connector designed for miniaturized electronic applications. It features bottom contact configuration with a hinged flip-lock actuator that secures the flexible printed circuit (FPC) cable to the connector terminals.
This solder termination type connector allows direct cable insertion without requiring mating connectors, offering a cost-effective wire-to-board interface. Its 1 mm pitch and 4 contact count make it suitable for precision connectivity to small displays, keyboards, and other compact devices.
Constructed with phosphor bronze contacts plated with tin over nickel and housed in durable polyamide, the connector ensures reliable electrical performance. It supports a maximum voltage rating of 100 V AC and current up to 1A, suitable for low-power signal applications.
The connector is designed for surface mount PCB assembly with a single row of horizontal female contacts positioned at the bottom, facilitating compact designs. Its operating temperature range from -40 °C to 105 °C allows use in various environmental conditions.
The locking mechanism utilizes a Zero Insertion Force (ZIF) flip-lock hinge actuator, simplifying installation while ensuring a secure connection, preventing accidental disconnection during use.
This connector is ideal for industrial, electronics manufacturing, consumer electronics, and automotive electronics requiring miniaturized, reliable flex cable connections. Its robust design and reliable locking feature offer durable, maintenance-free performance in challenging environments.
This WR-FPC series connector, model 686104148922, is made in China and meets typical industrial standards. Its compact form factor and secure cable lock make it a preferred choice in high-density PCB designs.
Explore our range of connectors and electronic components at EnvMart to find compatible parts and accessories that suit your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this FPC connector is 1 mm.
This model features 4 contact positions.
It supports a maximum operating voltage of 100 V AC.
The current rating for this connector is 1A.
It operates reliably in temperatures ranging from -40 °C to 105 °C.
This connector is designed for surface mount mounting on PCBs.
It is constructed with phosphor bronze contacts plated with tin over nickel and a polyamide housing.
The termination type for this connector is solder.
The contacts are arranged in a horizontal orientation with bottom contact configuration.
It is ideal for applications such as small displays and keyboard connections in miniaturized electronics.
It utilizes a Zero Insertion Force (ZIF) flip-lock hinged actuator for secure connections.
The connector is made in China.
