KEMET A72 Film Capacitor 22 nF ±10%, 1000 V DC 400 V AC, Through Hole A72QQ2220AA02K

KEMET A72QQ2220AA02K film capacitor is a high-performance passive electronic component designed for high-frequency and reliable circuit applications. Featuring a capacitance of 22 nF ±10%, it accommodates a rated DC voltage of 1000 V and AC voltage of 400 V, making it suitable for power electronics, filtering, and timing circuits.

The capacitor operates within a broad temperature range of -55°C to +105°C, ensuring robust performance in industrial, automotive, and consumer electronics environments. Constructed with polypropylene film and metal foil with axial leads, it offers excellent insulation and self-healing characteristics. The plastic casing protects the internal layers and provides mechanical stability.

This component complies with UL and IEC 60384-13 standards, delivering assured quality and safety. The thin lead diameter of 0.8 mm and 40 mm lead length support secure through-hole PCB mounting. With low dissipation factor of 0.1%, this capacitor minimizes energy loss and thermal buildup, optimizing circuit efficiency.

Typical applications include power supplies, signal filtering, pulse circuits, and other electronic systems requiring stable capacitance and voltage ratings. Packaging in tape and reel formats facilitates automated assembly processes.

The capacitor has a capacitance of 22 nF with ±10% tolerance. Rated AC voltage is 400 V, and DC voltage is 1000 V. The operating temperature range spans from -55°C to 105°C. Its axial lead mount type allows easy through-hole PCB installation.

It is constructed of polypropylene film with plastic casing. It meets UL and IEC 60384-13 standards for electrical safety and quality. Lead length measures 40 mm with 0.8 mm lead diameter. Pin count is 2, suitable for standard capacitor footprints.

Manufactured in Italy, providing European manufacturing quality. Explore the full range of Film Capacitors at EnvMart for reliable and industrial-grade electronic components.
