Wurth Elektronik WR-FPC 0.5 mm Pitch 45 Way Horizontal Female FPC Connector Solder 687145149022

Wurth Elektronik model 687145149022 is a precision FPC connector designed with a 0.5 mm pitch and 45 horizontal female contacts. This connector type employs a zero insertion force (ZIF) mechanism through a hinged flip-lock actuator, providing a robust and secure connection for flexible printed circuits.

The phosphor bronze contact material with tin over nickel plating ensures excellent electrical reliability and corrosion resistance. The polyamide housing provides mechanical strength and electrical insulation suitable for miniaturized electronic devices.

Designed for surface mount technology (SMT), this connector features solder termination at the bottom contact position, allowing for efficient PCB assembly with minimal risk of damage. Its operating voltage is rated at 50 volts AC with a current carrying capacity of 500mA, enabling use in low power electronic systems.

The connector's operating temperature range from -40°C to 105°C allows it to function reliably in a variety of industrial, commercial, and consumer electronics applications. Typical uses include connections to small displays, keyboards, and other compact electronic interfaces requiring a secure wire-to-board solution.

This WR-FPC series connectors combine a low profile, lightweight construction with high density and secure mechanical locking, meeting modern demands for space-saving electronic components in diverse fields such as industrial automation, telecommunications, consumer electronics, and embedded systems.

This FPC connector offers a 0.5 mm pitch for compact electronic assemblies. It features 45 contacts made of phosphor bronze for reliable conductivity. The connector has a hinged flip-lock actuator providing secure ZIF insertion force.

The housing material is polyamide, ensuring durability in harsh conditions. Suitable for SMT mounting with a solder termination type on bottom contact position. Operates safely within a voltage rating of 50 volts AC and current of 500mA.

The device withstands temperatures from -40°C to +105°C for a wide range of applications. Contact plating is tin over nickel to resist corrosion and maintain connection quality. The connector is manufactured in China adhering to standard quality expectations.

Customers sourcing Wurth Elektronik's 687145149022 FPC Connector benefit from a reliable, cost-effective solution for high-performance signal interconnects. This product is well suited for professional electronic design, manufacturing, and repair needs.
