Wurth Elektronik 1317 Series PCB Terminal Block, 6-Contact, 5 mm Pitch, Through Hole Mount, Horizontal 691131710006
Specifications
| Country of Origin | Hungary |
|---|---|
| Voltage | 450V ac |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Horizontal |
| Current | 22A |
| Length | 30mm |
| Depth | 15.5mm |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Series | 1317 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | cULus, RoHS, VDE |
| Number of Contacts | 6 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
Key Features
- Designed with a pressure clamp system using M2.5 screws for reliable conductor attachment.
- Constructed from grey UL94-V0 polycarbonate housing, ensuring flame retardant properties.
- Accepts solid and stranded wire sizes from 30 AWG (0.05 mm²) to 12 AWG (3.31 mm²).
- Rated for a maximum current of 22 A and voltage up to 450 V AC for robust performance.
- Compact size with dimensions 30 mm length, 8.5 mm width, and 15.5 mm depth for efficient PCB space utilization.
- Complies with international standards including cULus, RoHS, and VDE certifications.
- Manufactured in Hungary to ensure high quality and consistent production standards.
Product Description
Wurth Elektronik 691131710006 PCB Terminal Block is a 6-contact connector designed for printed circuit board (PCB) applications requiring secure and reliable electrical connections. It features a 5 mm pitch and a through-hole mount design with a single row layout, making it suitable for horizontal wire entry and compact PCB assemblies.
The terminal block utilizes a pressure clamp mechanism with M2.5 screws and zinc-plated steel clamps, providing firm and vibration-resistant conductor attachment. The housing is made of grey UL94-V0 rated polycarbonate, ensuring flame retardant properties and durability in demanding industrial and electronic environments.
This terminal block accommodates a wide range of wire gauges, accepting minimum wire sizes as small as 30 AWG (0.05 mm²) and maximum up to 12 AWG (3.31 mm²), supporting both solid and stranded wires. It is rated for a maximum current of 22 A and voltage of 450 V AC, suitable for power and signal distribution in electronic devices, control panels, industrial machinery, and automation systems.
Its compact dimensions of 30 mm length, 8.5 mm width, and 15.5 mm depth enable efficient use of PCB real estate while maintaining easy accessibility for wiring. The product complies with several international standards including cULus, RoHS, and VDE, assuring conformity to safety and environmental requirements.
Manufactured in Hungary with strict quality controls, this Wurth Elektronik 1317 Series PCB Terminal Block ensures dependable connections for industrial electronics, communication equipment, HVAC controls, manufacturing automation, and laboratory instrumentation.
Designed with a pressure clamp system using M2.5 screws for reliable conductor attachment. Constructed from grey UL94-V0 polycarbonate housing, ensuring flame retardant properties. Accepts solid and stranded wire sizes from 30 AWG (0.05 mm²) to 12 AWG (3.31 mm²).
Rated for a maximum current of 22 A and voltage up to 450 V AC for robust performance. Compact size with dimensions 30 mm length, 8.5 mm width, and 15.5 mm depth for efficient PCB space utilization. Complies with international standards including cULus, RoHS, and VDE certifications.
Manufactured in Hungary to ensure high quality and consistent production standards. Explore the Wurth Elektronik brand and the full range of PCB Terminal Blocks at EnvMart for your electronic component sourcing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block is rated for a maximum current of 22 A.
It accepts solid and stranded wire sizes ranging from 30 AWG (0.05 mm²) to 12 AWG (3.31 mm²).
The terminal block is rated for a maximum voltage of 450 V AC.
The dimensions are 30 mm in length, 8.5 mm in width, and 15.5 mm in depth.
It features a through-hole mount design suitable for horizontal wire entry.
It complies with cULus, RoHS, and VDE certifications.
The terminal block has a horizontal orientation with a single row layout.
The housing is constructed from grey UL94-V0 polycarbonate, ensuring flame retardant properties.
It utilizes a pressure clamp system with M2.5 screws for reliable conductor attachment.
It is manufactured in Hungary, ensuring high quality and consistent production standards.
This model features 6 contacts.
The terminal block has a pitch of 5 mm.
