Wurth Elektronik 2213 Series PCB Terminal Block, 5-Contact, 3.81 mm Pitch, Through Hole, 1 Row 691221320005
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 1.6kV |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | 55° |
| Current | 10A |
| Length | 19.05mm |
| Depth | 9.5mm |
| Width | 10mm |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Series | 2213 |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Number of Contacts | 5 |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 1.3mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Rising Cage Clamp |
Key Features
- Features a polyamide housing ensuring durability and insulation.
- Supports current up to 10 amperes for moderate power applications.
- Accepts wire sizes from 0.08 mm² to 1.3 mm², compatible with 28 to 16 AWG wires.
- Provides a rising cage clamp wire connection method for secure wiring.
- Designed in a single row configuration with 5 contacts for efficient PCB integration.
- Compact dimensions include 19.05 mm length, 10 mm width, and 9.5 mm depth.
- Green color body with 55° orientation suits various PCB layouts.
Product Description
Wurth Elektronik 691221320005 PCB Terminal Block, part of the 2213 Series, presents a robust and reliable solution for industrial and electronic PCB wiring applications. This 5-contact, single row terminal block with a 3.81 mm pitch is designed for through-hole mounting to ensure a secure mechanical and electrical connection.
Featuring a polyamide housing, it offers excellent durability and electrical insulation, making it suitable for demanding environments. The terminal block supports a current capacity of 10 amperes, accommodating wire sizes ranging from 0.08 mm² up to 1.3 mm² (28 AWG to 16 AWG), providing flexibility for varying conductor types.
The wire connection is handled by a rising cage clamp method, ensuring firm and maintenance-free connections. Its compact dimensions (length 19.05 mm, width 10 mm, depth 9.5 mm) and green color enhance visibility and integration on printed circuit boards. The unit operates reliably with a voltage rating of 1.6 kilovolts and has a 55-degree orientation to facilitate PCB design requirements.
This terminal block is well suited for industrial automation, power supply connections, electronic equipment manufacturing, HVAC control systems, and other commercial and manufacturing applications requiring secure signal or power terminations.
Features a polyamide housing ensuring durability and insulation. Supports current up to 10 amperes for moderate power applications. Accepts wire sizes from 0.08 mm² to 1.3 mm², compatible with 28 to 16 AWG wires. Provides a rising cage clamp wire connection method for secure wiring.
Designed in a single row configuration with 5 contacts for efficient PCB integration. Voltage rating of 1.6 kV offers robust insulation resistance. Compact dimensions include 19.05 mm length, 10 mm width, and 9.5 mm depth.
Green color body with 55° orientation suits various PCB layouts. Explore more in the PCB Terminal Blocks category at EnvMart for compatible components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current capacity of 10 amperes, making it suitable for moderate power applications.
The voltage rating is 1.6 kilovolts, providing robust insulation resistance for various applications.
It accepts wire sizes ranging from 0.08 mm² to 1.3 mm², which corresponds to 28 AWG to 16 AWG wires.
The terminal block utilizes a rising cage clamp wire connection method for secure and maintenance-free wiring.
The dimensions are 19.05 mm in length, 10 mm in width, and 9.5 mm in depth.
It features 5 contacts in a single row configuration for efficient PCB integration.
The pitch size is 3.81 mm, which is standard for many PCB applications.
The housing is made of polyamide, ensuring durability and electrical insulation.
It is designed with a 55-degree orientation to facilitate various PCB layouts.
The country of origin for this terminal block is China.
It is well suited for industrial automation, power supply connections, electronic equipment manufacturing, and HVAC control systems.
Yes, it is designed for through-hole mounting, ensuring a secure mechanical and electrical connection.
