TDK Standard Metal Oxide Varistor 19 nF Capacitance 20 A Clamping 43 V, Varistor Voltage 22 V B72220S0140K101

Free Delivery in India | Lowest Global Shipping Charges

TDK Standard Metal Oxide Varistor 19 nF Capacitance 20 A Clamping 43 V, Varistor Voltage 22 V B72220S0140K101



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	21.5mm
Brand	TDK
Material	Metal
THICKNESS	4.6mm
Length	25.5mm
Model	B72220S0140K101
Packaging	Bulk
Series	Standard
Energy Rating	12J
Maximum Operating Temperature	85°C
Capacitance	19nF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	18V dc
Standards/Approvals	CQC, CSA, IEC, UL, VDE
Pin Count	2
Termination Style	Solder
Lead Pitch	10mm
Maximum AC Voltage	14V ac
Clamping Voltage VC	43V
Clamping Current	20A
Maximum Surge Current	2kA
Varistor Voltage	22 V

Key Features

Features a varistor voltage of 22 V ensuring effective voltage clamping.
Has a clamping voltage of 43 V for reliable surge suppression.
Constructed with a metal oxide material for high durability.
Operates within temperature range of -40°C to 85°C for stable performance.
Comes with a compact diameter of 21.5 mm and length of 25.5 mm for easy installation.
Supports maximum surge current rating of 2 kA handling transient spikes effectively.
Equipped with solder termination and 10 mm lead pitch for standard circuit integration.
Complies with industry standards including CQC, CSA, IEC, UL, and VDE for quality assurance.

Product Description

TDK B72220S0140K101 Standard Metal Oxide Varistor is a reliable surge protection component designed to protect sensitive electronic circuits from transient voltage surges. With a capacitance of 19 nF and a varistor voltage of 22 V, this component effectively clamps voltage spikes to a maximum clamping voltage of 43 V.

The varistor supports a high clamping current of 20 A and can absorb surge currents up to 2 kA, making it suitable for a broad range of industrial and commercial electronics applications.

Its robust metal oxide construction ensures long-term reliability, while the epoxy coating provides protection against environmental factors. It operates efficiently across a temperature range from -40°C to 85°C, making it adaptable to various operating environments.

The varistor features solder termination and a lead pitch of 10 mm for easy PCB mounting and integration. With a diameter of 21.5 mm and length of 25.5 mm, it is compact and space-saving.

This product meets recognized international standards including CQC, CSA, IEC, UL, and VDE, assuring users of its quality and safety compliance. Typical applications include surge suppression in power supplies, industrial control systems, and general electronic device protection.

Features a varistor voltage of 22 V ensuring effective voltage clamping. Has a clamping voltage of 43 V for reliable surge suppression. Constructed with a metal oxide material for high durability. Operates within temperature range of -40°C to 85°C for stable performance.

Comes with a compact diameter of 21.5 mm and length of 25.5 mm for easy installation. Supports maximum surge current rating of 2 kA handling transient spikes effectively. Equipped with solder termination and 10 mm lead pitch for standard circuit integration.

Complies with industry standards including CQC, CSA, IEC, UL, and VDE for quality assurance. Offers energy rating of 12 J suitable for standard surge energy absorption. Explore more Varistors and Surge Protection Components in the Electronics Components category at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The varistor voltage of this model is 22 V, which ensures effective voltage clamping during transient surges.

It has a maximum clamping voltage of 43 V, providing reliable surge suppression for sensitive electronic circuits.

This model supports a maximum surge current rating of 2 kA, allowing it to handle significant transient spikes effectively.

The capacitance of this varistor is 19 nF, which is suitable for various surge protection applications.

It has a diameter of 21.5 mm and a length of 25.5 mm, making it compact for easy installation.

This model operates within a temperature range of -40°C to 85°C, ensuring stable performance in various environments.

It features solder termination with a lead pitch of 10 mm, facilitating standard circuit integration.

The energy rating of this varistor is 12 J, suitable for standard surge energy absorption applications.

This model complies with several industry standards, including CQC, CSA, IEC, UL, and VDE, ensuring quality assurance.

The clamping current for this varistor is rated at 20 A, providing reliable performance during surge events.

It is constructed with a metal oxide material, which contributes to its durability and effectiveness in surge protection.

This varistor is suitable for applications such as surge suppression in power supplies, industrial control systems, and general electronic device protection.
