TDK Standard Metal Oxide Varistor 1.6nF 2.5A Clamping Voltage 2970V Diameter 9mm B72207S0200K101
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 9mm |
| Brand | TDK |
| Material | Metal |
| THICKNESS | 3.6mm |
| Length | 36mm |
| Model | B72207S0200K101 |
| Depth | 3.6mm |
| Mount Type | Lead |
| Series | Standard |
| Energy Rating | 1J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 1.6nF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 1465V dc |
| Standards/Approvals | CSA, VDE, CQC, IEC, UL |
| Pin Count | 2 |
| Termination Style | Radial |
| Lead Pitch | 5mm |
| Maximum AC Voltage | 1100V ac |
| Clamping Voltage VC | 2970V |
| Clamping Current | 2.5A |
| Maximum Surge Current | 250A |
| Varistor Voltage | 33 V |
Key Features
- Rated clamping voltage of 2970V for effective voltage spike absorption.
- Metal oxide varistor type for enhanced durability and performance.
- Compact 9mm diameter with 36mm length suitable for various electronics applications.
- Capacitance of 1.6nF supports stable operation in sensitive circuits.
- Radial termination style with 5mm lead pitch for easy PCB mounting.
- Operating temperature range from -40°C to 85°C for versatile environment usage.
- Energy rating of 1 Joule for transient energy dissipation.
- Complies with CSA, VDE, CQC, IEC, and UL approvals ensuring quality and safety standards.
Product Description
TDK B72207S0200K101 is a Standard Metal Oxide Varistor designed for surge protection in electronic devices. Featuring a capacitance of 1.6nF and a clamping current rating of 2.5A, this varistor clamps voltage spikes effectively at 2970V, safeguarding sensitive circuits from transient surges.
This radial leaded component has a 9mm diameter and a length of 36mm, coated with epoxy resin for enhanced durability. It operates reliably across a temperature range of -40°C to 85°C, making it suitable for industrial, laboratory, and commercial electronic applications.
The varistor is rated for a maximum AC voltage of 1100V and maximum DC voltage of 1465V, with a maximum surge current of 250A. Its lead pitch of 5mm facilitates mounting on printed circuit boards. The product also holds certifications from multiple international standards organizations including CSA, VDE, CQC, IEC, and UL.
TDK's Metal Oxide Varistors are widely used in electronics for transient voltage suppression, helping protect devices from electrical surges and spikes common in industrial environments and power supply systems.
Rated clamping voltage of 2970V for effective voltage spike absorption. Compact size with 9mm diameter and 36mm length. Capacitance of 1.6nF supports stable operation in sensitive circuits. Suitable for use in industrial, laboratory, and commercial electronics protection.
Complies with multiple international safety and quality standards. Explore additional TDK components and Varistors at EnvMart for comprehensive surge protection solutions tailored to your electrical and electronics engineering requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of the TDK B72207S0200K101 is rated at 2970V, providing effective voltage spike absorption.
This varistor has a capacitance of 1.6nF, which supports stable operation in sensitive circuits.
The maximum operating temperature for this model is 85°C, allowing it to function in a variety of environments.
It features a lead pitch of 5mm, facilitating easy mounting on printed circuit boards.
The maximum surge current for this varistor is rated at 250A, ensuring it can handle significant transient events.
The varistor has a diameter of 9mm and a length of 36mm, making it compact for various applications.
This model has an energy rating of 1 Joule, which indicates its capacity for transient energy dissipation.
The minimum operating temperature for this varistor is -40°C, allowing it to be used in colder environments.
It complies with multiple international standards including CSA, VDE, CQC, IEC, and UL, ensuring quality and safety.
The termination style is radial, which is common for easy integration into electronic circuits.
The maximum DC voltage rating for this model is 1465V, providing a limit for safe operation in DC applications.
This varistor is suitable for surge protection in industrial, laboratory, and commercial electronic applications.
