TDK Standard Metal Oxide Varistor 2.4nF 5A Clamping 110V Diameter 12mm B72210S0350K101

TDK B72210S0350K101 standard metal oxide varistor is engineered to provide effective surge protection in electronic and electrical circuits. Rated for a capacitance of 2.4 nanofarads, a maximum clamping current of 5 amperes, and a clamping voltage of 110 volts, this varistor helps safeguard sensitive components from voltage spikes and transient surges induced by switching events or lightning strikes.

The varistor features a metal oxide composition with a standard radial epoxy-coated ceramic body, ensuring durability and stable electrical characteristics. The varistor voltage rating of 56 volts defines the voltage level at which it begins to conduct significantly, thereby clamping excessive voltages within safe limits.

It operates reliably within a temperature range from -40°C up to 85°C, making it suitable for diverse industrial, commercial, and laboratory applications. Its dimensions include a 12 mm diameter, 14.5 mm length, and a thickness of 4.4 mm with two tinned copper wire leads having a 7.5 mm lead pitch, facilitating straightforward PCB solder mounting.

With a maximum surge current rating of 500 A and an energy handling capacity of 5.4 Joules, this varistor can absorb high transient energy impulses while maintaining circuit integrity. The solder termination style and compact form factor support ease of installation in various electronic assemblies.

The product meets international standards and certifications from UL, CSA, VDE, CQC, and EC, ensuring compliance with safety and quality requirements. This varistor is ideal for use in protection circuits in industrial electronics, power supply modules, HVAC control systems, telecommunications, and other sensitive electronic equipment.

Metal oxide varistor designed for surge protection applications. Rated varistor voltage: 56 V for transient voltage suppression. Maximum AC voltage rating of 35V and DC voltage of 45V. Capacitance value of 2.4nF with 2 pins for through-hole soldering.

Dimensions include 12mm diameter, 14.5mm length, and 4.4mm thickness. Operating temperature range from -40°C up to 85°C. Energy rating of 5.4 Joules suitable for transient energy absorption. Standard radial epoxy-coated varistor with epoxy resin coated ceramic body.

Tinned copper wire leads with solder termination style for easy PCB mounting. Approvals include UL, CSA, VDE, CQC, and EC for quality and safety compliance. Explore more TDK Varistors for reliable transient voltage suppression in your electronics on EnvMart.
