Schurter Non-Resettable Fuse 12.5A, 125V DC, 250V AC, Ceramic Body, Time Delay, Model 3403.0285.23

Free Delivery in India | Lowest Global Shipping Charges

Schurter Non-Resettable Fuse 12.5A, 125V DC, 250V AC, Ceramic Body, Time Delay, Model 3403.0285.23

Name: Schurter Non-Resettable Fuse 12.5A, 125V DC, 250V AC, Ceramic Body, Time Delay, Model 3403.0285.23
Brand: Schurter
SKU: 146413
Price: 3142.62 USD
Availability: InStock



Category Non Resettable Fuse Brand Schurter Condition New

Specifications

Country of Origin	Switzerland
Voltage	125, 250V dc
Brand	Schurter
Body Material	Ceramic
Height	5.6mm
Depth	15.4mm
Width	5.35mm
Current Rating	12.5A
Series	UMT-H
Maximum Operating Temperature	-55°C
Package Type	Reel
Minimum Operating Temperature	125°C
Breaking Capacity	1500A
Terminal Material	Copper
Standards/Approvals	CSA, REACH, UL 248-14, CE, RoHS
Fuse Characteristics	Time Delay

Key Features

Rated for 12.5 amps current rating ensuring reliable circuit protection.
Electrical voltage ratings are 125 volts DC and 250 volts AC.
Ceramic body offers durability and impermeability to potting compounds.
Time delay fuse characteristic suitable for pulse-shaped continuous currents.
Operating temperature range from -55°C minimum to 125°C maximum.
High breaking capacity of up to 1500 amps for demanding applications.
Compact surface mount design with copper alloy terminals for excellent conductivity.
Compliant with applicable CSA, REACH, UL 248-14, CE, and RoHS standards.

Product Description

Schurter 3403.0285.23 Non-Resettable Fuse is a high-quality surface mount fuse specifically designed for electronic circuit protection with a ceramic housing and copper alloy terminals. It provides reliable protection with a current rating of 12.5 amps and dual voltage capability of 125V DC and 250V AC. Its ceramic body ensures robustness and is impermeable to potting compounds, satisfying intrinsically safe application requirements.

The fuse features a time delay characteristic that makes it suitable for pulse-shaped continuous current applications, minimizing unnecessary interruptions. It can safely operate in a wide temperature range between -55 degrees Celsius and 125 degrees Celsius, while offering a high breaking capacity of up to 1500 amps to handle short circuit conditions effectively.

This model 3403.0285.23 fuse meets multiple international standards including CSA, REACH, UL 248-14, CE, and RoHS, assuring compliance and quality. Its compact surface mount design facilitates integration into printed circuit boards while maintaining dependable electrical performance through its copper terminals.

Typical applications include battery protection, illumination systems, and power supplies in industrial and commercial environments. This fuse provides primary protection for PCB and surface mount device circuits against overcurrent conditions.

Rated at 12.5A current to protect circuits effectively. Ceramic body housing ensures mechanical and environmental resilience. Time delay fuse characteristic supports pulse current tolerance. Dual voltage rating of 125V DC and 250V AC enhances versatility.

Wide operating temperature range from -55°C to 125°C for reliability in various environments. High breaking capacity up to 1500A for enhanced safety. Complies with CSA, REACH, UL, CE, and RoHS standards for assured quality.

Ideal for use in battery protection, illumination, and power supply circuits. Explore our extensive range of Schurter fuses and electrical components at EnvMart for industrial, laboratory, and commercial electrical protection solutions.
