Bourns Shielded Surface Mount Inductor 7032 Case 100μH ±20% 500mA Max DC Current Wirewound Ferrite DR & RI Core SRR7032
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 3.2mm |
| Length | 7mm |
| Model | SRR7032 |
| Depth | 7mm |
| Packaging | Reel |
| Series | SRR7032 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite DR & RI |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Package/Case | 7032 |
| Maximum DC Current | 500mA |
| Maximum DC Resistance | 540mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 12MHz |
| Minimum Quality Factor | 28 |
| Inductor Construction | Wirewound |
Key Features
- This wirewound inductor supports a maximum DC current of 500mA.
- It features magnetic shielding and a surface mount termination style.
- Operating temperature range is from -40°C to 125°C ensuring reliability in varied conditions.
- Maximum DC resistance is 540mΩ for efficient performance.
- Compact dimensions of 7mm length, 3.2mm height, and 7mm depth suit PCB mounting applications.
- It is supplied in reel packaging suitable for automated assembly processes.
- Maximum self-resonant frequency is 12MHz with a minimum quality factor of 28.
- Constructed with moulded design and ferrite core material to optimize magnetic properties.
Product Description
Bourns SRR7032 shielded surface mount inductor is designed for demanding electronic applications requiring compact and reliable inductors. This model features a 7032 case size with ferrite DR & RI core material, providing an inductance of 100μH ±20% tolerance. The wirewound construction ensures stable performance and magnetic shielding minimizes electromagnetic interference.
Supporting a maximum DC current of 500mA, SRR7032 is ideal for use in DC/DC converters and power supplies for portable communication devices, LCD TVs, camcorders, and car radios. Its wide operating temperature range from -40°C to 125°C allows usage in various industrial, commercial, and consumer electronics environments.
The inductor’s low maximum DC resistance of 540mΩ improves energy efficiency, while the maximum self-resonant frequency of 12MHz and minimum quality factor of 28 contribute to excellent frequency response. Its compact dimensions of 7mm length, 3.2mm height, and 7mm depth facilitate easy PCB mounting and integration in space-constrained designs.
SRR7032 inductors come in reel packaging, well-suited for automated PCB assembly lines, ensuring high throughput production. The molded design and ferrite core provide mechanical robustness and thermal stability, enhancing product lifespan and performance consistency.
This Bourns series is RoHS compliant, ensuring environmentally safe material usage. It is commonly used in industrial manufacturing, telecommunications, consumer electronics, and automotive applications as a reliable surface mount power inductor.
This wirewound, shielded surface mount inductor features a ferrite DR & RI core. Provides 100μH inductance with ±20% tolerance and supports 500mA maximum DC current. Compact 7032 package size with dimensions suitable for PCB automated assembly.
Wide operating temperature range (-40°C to 125°C) and low DC resistance (540mΩ). RoHS compliant and designed for demanding electronic applications including DC/DC converters and power supplies. Explore more Bourns electronic components and Surface Mount Inductors in EnvMart's extensive catalog for industrial and commercial use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns SRR7032 has an inductance value of 100μH with a tolerance of ±20%.
This model supports a maximum DC current of 500mA.
The dimensions of the SRR7032 are 7mm in length, 3.2mm in height, and 7mm in depth.
The operating temperature range for the Bourns SRR7032 is from -40°C to 125°C.
The maximum self-resonant frequency of this inductor is 12MHz.
This inductor features a ferrite DR & RI core material.
The maximum DC resistance for the SRR7032 is 540mΩ.
It is supplied in reel packaging, which is suitable for automated assembly processes.
The minimum quality factor of the SRR7032 is 28.
This model features a surface mount termination style.
Yes, the SRR7032 is RoHS compliant, ensuring environmentally safe material usage.
This inductor is suitable for use in DC/DC converters and power supplies for various electronic devices, including portable communication devices and automotive applications.
