Bourns Shielded Surface Mount Inductor Ferrite Core 68μH ±30% 800mA DC Current 10.5MHz SRR6028
Specifications
| Country of Origin | China |
|---|---|
| Brand | Bourns |
| Height | 2.8mm |
| Length | 6.8mm |
| Model | SRR6028 |
| Depth | 6.8mm |
| Packaging | Reel |
| Series | SRR6028 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 6028 |
| Maximum DC Current | 800mA |
| Maximum DC Resistance | 300mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 10.5MHz |
| Minimum Quality Factor | 11 |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded wire wound inductor for stable operation.
- Designed with 800mA maximum DC current rating.
- Compact 6028 package with dimensions 6.8mm length and 2.8mm height.
- Maximum operating temperature up to 125°C ensures durability.
- Suitable for DC/DC converter input/output and power supply applications.
- Ferrite core improves magnetic performance and reduces interference.
- RoHS compliant with wirewound construction and surface mount termination style.
- Minimum quality factor of 11 supports efficient energy storage.
Product Description
Bourns SRR6028 shielded surface mount inductor with ferrite core offers 68μH inductance with ±30% tolerance and supports up to 800mA DC current. With a compact 6028 package size measuring 6.8mm in length, 6.8mm in depth, and 2.8mm in height, it is ideal for compact, high-frequency power electronics.
These magnetically shielded wire wound inductors are designed for use in DC/DC converters, power supplies, and portable communication equipment, including camcorders, LCD TVs, and car radios. The ferrite core material provides excellent magnetic characteristics while the shielding reduces electromagnetic interference.
The SRR6028 series components maintain performance at temperatures ranging from -40°C to 125°C. They feature a maximum DC resistance of 300mΩ and a maximum self-resonant frequency of 10.5MHz, with a minimum quality factor of 11 ensuring efficient energy storage and minimal losses.
The inductor is RoHS compliant, mounted using a surface mount style termination, and moulded for durability. Packaged on reels, this component facilitates automated assembly and high-volume production.
Magnetically shielded wire wound construction. Ferrite core reduces magnetic interference. Compact 6028 SMD package suitable for dense PCB layouts. Operating temperature range from -40°C to 125°C. Maximum DC current rating of 800mA.
Maximum self-resonant frequency of 10.5MHz. RoHS compliant and environmentally friendly. Applications include DC/DC converters, power supplies, and portable electronics. These inductors support diverse industrial applications including electronics manufacturing, telecommunications equipment, consumer electronics, and automotive electronics.
Explore more quality Electronic Components and inductors at EnvMart for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRR6028 inductor has an inductance value of 68μH with a tolerance of ±30%.
This model supports a maximum DC current rating of 800mA.
The dimensions of the SRR6028 inductor are 6.8mm in length, 6.8mm in depth, and 2.8mm in height.
The maximum operating temperature for this inductor is 125°C.
The SRR6028 uses a surface mount termination style.
The maximum self-resonant frequency of the SRR6028 inductor is 10.5MHz.
This model has a minimum quality factor of 11, which supports efficient energy storage.
The SRR6028 inductor is constructed with a ferrite core and features wirewound construction.
Yes, the SRR6028 inductor is RoHS compliant, indicating it meets environmental regulations.
This inductor is suitable for use in DC/DC converters, power supplies, and portable communication equipment.
The maximum DC resistance for the SRR6028 inductor is 300mΩ.
The SRR6028 inductor is packaged on reels, facilitating automated assembly and high-volume production.
