TE Connectivity SL-156 Female Connector Housing 3.96 mm Pitch 10 Way 1 Row Straight 1-640250-0
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Length | 39.57mm |
| Width | 7.27mm |
| Mount Type | Cable |
| Housing Material | Nylon |
| Series | SL-156 |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| For Use With | Wire-to-Board Economy Power Connector |
| Number of Contacts | 10 |
| Connector Gender | Female |
Key Features
- Constructed from UL94V-0 rated nylon material for enhanced durability.
- Designed to mate with 1.14 mm square or round post headers on 3.96 mm centers.
- Supports wire sizes ranging from 18 to 24 AWG for versatile cable applications.
- Offers end-to-end stackable housings to allow secure and modular connections.
- Available with locking ramp mating retention and polarizing tabs for reliable contacts.
- Compatible with SL-156 series crimp contacts for efficient assembly.
- Ideal for wire-to-board economy power connector systems in electronic applications.
- Compact dimensions with length of 39.57 mm and width of 7.27 mm.
Product Description
TE Connectivity 1-640250-0 is a female connector housing from the SL-156 series, featuring a 3.96 mm pitch and a 10 way, 1 row straight design. Manufactured from UL94V-0 rated white nylon, this housing delivers robust insulation and flame resistance for high reliability in electronic connector assemblies.
This connector housing mates with 1.14 mm square or round post headers designed on 3.96 mm centers, suitable for wire-to-board economy power connector applications. Its design accommodates wire sizes sized between 18 to 24 AWG, providing flexibility for various wiring needs.
The SL-156 housings are end-to-end stackable, which facilitates modular configurations and space-efficient installations in complex electronic systems. Additionally, this model can include locking ramp mating retention and polarizing tabs, ensuring secure connections and preventing mismating during assembly.
Compatible crimp contacts for these connectors can be sourced with stock number 680-1792, typical for the series, providing comprehensive assembly solutions. Constructed from flame-retardant nylon material offering durability.
Designed for 3.96 mm pitch with 10 contact positions in a single row. Compatible with multiple wire gauge sizes (18-24 AWG) for versatility. Stackable housings enable scalable and modular electronic designs. Locking ramp and polarizing tabs enhance connection security and reliability.
Compact size with precise 39.57 mm length and 7.27 mm width. Female connector housing ideal for wire-to-board power connector systems. Supports industrial electronics, laboratory equipment, manufacturing, and automotive use cases.
This TE Connectivity SL-156 female connector housing is designed to meet demanding standards of modern electronics manufacturing and assembly. It is suitable for applications in industrial automation, manufacturing control panels, communications equipment, and general electronic hardware interface connections.
Explore EnvMart's vast catalog of TE Connectivity connectors and housing solutions to find compatible components and gain access to high-quality parts that optimize performance and reliability.
Explore more products in our Electronic Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this connector housing is 3.96 mm.
It supports 10 contacts in a single row configuration.
This model accommodates wire sizes ranging from 18 to 24 AWG.
The connector housing has a length of 39.57 mm and a width of 7.27 mm.
The housing is constructed from UL94V-0 rated nylon material, providing flame resistance and durability.
Yes, the SL-156 housing is designed to be end-to-end stackable for modular configurations.
This model supports cable mounting.
The orientation of this connector housing is straight.
It is ideal for wire-to-board economy power connector systems in various electronic applications, including industrial automation and manufacturing.
This housing belongs to the SL-156 series of connectors.
The connector gender of this model is female.
The country of origin for this connector housing is India.
