Wurth Elektronik WE-GF 1210 Unshielded Wirewound Surface Mount Inductor 0.22 μH ±20% 450 mA Idc 744764002
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2.2mm |
| Length | 3.2mm |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 0.22μH |
| Standards/Approvals | REACH, RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 450mA |
| Pin Count | 2 |
| Maximum DC Resistance | 320mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 350MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Unshielded wirewound construction suitable for HF circuits.
- Rated maximum DC current of 450 mA for reliable operation.
- Compact 1210 package size with dimensions 3.2mm length, 2.2mm height, and 2.5mm depth.
- Maximum DC resistance of 320 mΩ ensuring efficient performance.
- Operating temperature range from -40°C up to 105°C for versatility.
- Core made of ferrite material to support high frequency signals up to 350 MHz self-resonant frequency.
- Designed for use in HF amplifiers, oscillators, transponders, LC filter circuits, and tuners.
- Tape & reel packaging optimized for automated surface mount assembly.
Product Description
Wurth Elektronik 744764002 WE-GF 1210 series unshielded wirewound surface mount inductor features a ferrite core with 0.22 μH inductance and ±20% tolerance. It has a maximum DC current rating of 450 mA and is built in a 1210 package with surface mount termination style.
This inductor exhibits a maximum DC resistance of 320 mΩ and operates reliably in temperature conditions ranging from -40°C to 105°C. The ferrite core facilitates high frequency performance up to its maximum self-resonant frequency of 350 MHz, making this component ideal for high frequency applications such as HF amplifiers, oscillators, transponders, LC filter circuits, and tuner networks.
The wirewound construction ensures quality inductance with a minimum quality factor of 30. Its compact dimensions of 3.2mm length, 2.2mm height, and 2.5mm depth allow easy integration into PCB layouts requiring surface mount components.
Packaged in tape & reel format, this component suits automated manufacturing environments and enables efficient insertion into machinery for mass production. This product complies with REACH and RoHS standards, assuring environmentally safe and regulation-compliant use.
Unshielded wirewound design optimized for high frequency circuits. Maximum DC current of 450 mA supports diverse application loads. Compact 1210 package ensures space efficiency on PCBs. Ferrite core material contributes to high frequency stability.
Broad operating temperature range enhances versatility in various environments. High self-resonant frequency of 350 MHz enables application in advanced communication systems. Tape & reel packaging facilitates automated surface mount assembly processes.
Conforms to REACH and RoHS environmental and safety standards. Ideal for industrial electronics, telecommunications, and high-frequency signal applications, the Wurth Elektronik WE-GF 744764002 is engineered for precision and durability.
Explore more Surface Mount Inductors and electronic components in the Electronics & Electricals category at EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 0.22 μH with a tolerance of ±20%.
It has a maximum DC current rating of 450 mA, ensuring reliable operation in various applications.
This inductor has dimensions of 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth.
The maximum self-resonant frequency is 350 MHz, making it suitable for high frequency applications.
It operates within a temperature range of -40°C to 105°C, providing versatility in various environments.
The core material of this inductor is ferrite, which supports high frequency performance.
The maximum DC resistance is 320 mΩ, ensuring efficient performance in circuits.
It is packaged in tape & reel format, optimized for automated surface mount assembly processes.
The minimum quality factor is 30, which indicates its effectiveness in high frequency applications.
This inductor complies with REACH and RoHS standards, ensuring environmentally safe use.
It is designed for use in HF amplifiers, oscillators, transponders, LC filter circuits, and tuner networks.
The termination style of this inductor is surface mount, suitable for PCB integration.
