TDK Screw EMC Filter Terminal Block 1 Phase 12 A 250V AC/DC 60Hz B84142B0012R000

Free Delivery in India | Lowest Global Shipping Charges

TDK Screw EMC Filter Terminal Block 1 Phase 12 A 250V AC/DC 60Hz B84142B0012R000



Category Power Line Filters Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	61mm
Length	113mm
Model	B84142B0012R000
Depth	144mm
Mount Type	Screw
Operating Frequency	60Hz
Series	B84142B*R000
Maximum Operating Temperature	100°C
Resistance	30mΩ
Minimum Operating Temperature	-25°C
Maximum Current	12A
Number of Phases	1
Leakage Current	2.77mA
Maximum Voltage	250V ac/dc
Standards/Approvals	IEC 60939
Termination Style	Terminal Block
TDK, B84142A 10 A 250V ac/dc 60Hz, Flange EMC Filter, Screw 1 PhaseBrand	TDK

Key Features

Rated for a maximum current of 12 A.
Operates at a maximum voltage of 250V AC/DC and frequency of 60Hz.
Features sturdy screw mounting and terminal block termination style.
Designed for single-phase power line filtering applications.
Offers low leakage current of 2.77 mA with 30 mΩ resistance.
Can operate in temperatures from -25°C up to 100°C.
Complies with IEC 60939 standard and UL1283, CSA22.2 No.8 approvals.
Suitable for motor drives, pumps, elevators, HVAC systems, and power supplies.

Product Description

TDK B84142B0012R000 Screw EMC Filter Terminal Block is a high-performance power line filter designed for single-phase applications. Rated for 12 A and 250 V AC/DC, this filter operates at 60 Hz frequency and incorporates two-stage construction ensuring high insertion loss and efficient electromagnetic interference suppression.

Equipped with robust screw mounting and terminal block termination style, it offers reliable and easy installation in various industrial and commercial environments. Its compact dimensions - length of 113 mm, depth of 144 mm, and height of 61 mm - make it suitable for integration into constrained spaces.

The filter performs reliably under a wide operating temperature range from -25°C to 100°C and features a low leakage current of 2.77 mA with a resistance of 30 mΩ, guaranteeing minimal energy loss. Compliance with IEC 60939 standards and approvals such as UL1283 and CSA22.2 No.8 underscore its quality and safety credentials.

This EMC filter is ideal for use with frequency converters for motor drives, pumps, elevators, conveyor systems, HVAC systems, DC applications, and power supplies. Its optimized leakage current and two-stage filter design ensure effective noise suppression in sensitive electrical equipment.

Rated maximum current of 12 A for robust operation. Voltage rating up to 250 V AC/DC suitable for diverse power lines. Screw mounting and terminal block termination ensure durable connections. Single-phase design fits standard industrial single-phase circuits.

Compact and durable form factor measuring 113 mm × 144 mm × 61 mm. Low leakage current of 2.77 mA minimizes power losses. Wide temperature performance range from -25°C to 100°C. Certified to IEC 60939, UL1283, and CSA22.2 No.8 for safety and performance.

Applications include motor drives, pumps, elevators, HVAC, and power supplies.

Manufactured in China, this EMC filter supports reliable operation in industrial, laboratory, HVAC, and manufacturing sectors. Explore EnvMart’s catalog for more TDK Power Line Filters and compatible EMI filter solutions tailored to your application needs.
