Molex SL Series Right Angle Surface PCB Header 3 Contact, 2.54 mm Pitch, 1 Row, Shrouded 15913034
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Model | 15913034 |
| Mount Type | Surface |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass, Phosphor Bronze |
| Series | SL |
| Termination Type | Tin |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CSA LR19980, UL E29179 |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The header features a shrouded design to ensure secure connections.
- It has a single row with 3 male contacts suitable for surface mounting.
- The pitch between contacts is a standard 2.54 mm for compatibility.
- Contacts are made from brass and phosphor bronze with tin plating for durability.
- Supports operating voltages up to 250 V and currents up to 3 A.
- Housing material is high temperature thermoplastic supporting harsh environments.
- Minimum and maximum operating temperatures are -40°C and 105°C respectively.
- Certified to standards CSA LR19980 and UL E29179 for safety and reliability.
Product Description
Molex 15913034 SL Series Right Angle Surface PCB Header features 3 male contacts arranged in one row with a 2.54 mm pitch, ideal for precise wire-to-board connections.
This header utilizes a high temperature thermoplastic housing which ensures durability under temperatures ranging from -40°C to 105°C, suitable for demanding industrial environments.
The brass and phosphor bronze contacts plated with tin provide excellent conductivity and corrosion resistance, ensuring long-term reliability. The shrouded design improves connection security and reduces risk of misalignment during assembly or operation, making it suited for surface mounting on PCBs.
Rated for operating voltages up to 250 V and currents up to 3 A, this connector meets the requirements for various electronic and electrical applications. It has certifications including CSA LR19980 and UL E29179, confirming its adherence to recognized industry safety standards.
This product is widely used in electronics manufacturing, industrial automation, and power distribution systems requiring robust PCB header connectors. The packaging typically includes the header in tubes of 46 pieces for efficient inventory and handling.
The header features a shrouded design to ensure secure connections. It has a single row with 3 male contacts suitable for surface mounting. The pitch between contacts is a standard 2.54 mm for compatibility. Contacts are made from brass and phosphor bronze with tin plating for durability.
Supports operating voltages up to 250 V and currents up to 3 A. Housing material is high temperature thermoplastic supporting harsh environments. Minimum and maximum operating temperatures are -40°C and 105°C respectively.
Certified to standards CSA LR19980 and UL E29179 for safety and reliability. Designed for industrial, electronic component, and electrical PCB connector applications. Explore more PCB Header connectors and other electronic components on EnvMart to fulfill your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 2.54 mm, which is a standard spacing for compatibility with various applications.
This model has a maximum operating temperature of 105°C, making it suitable for demanding environments.
It supports operating voltages up to 250 V and currents up to 3 A, suitable for various electronic applications.
The contacts are made from brass and phosphor bronze, plated with tin for enhanced conductivity and corrosion resistance.
This header is designed for surface mounting, allowing for easy integration onto printed circuit boards.
It features 3 male contacts arranged in a single row, facilitating precise wire-to-board connections.
This product is certified to CSA LR19980 and UL E29179 standards, ensuring adherence to recognized safety standards.
The orientation of this header is right angle, which helps in fitting into tight spaces on PCBs.
The housing is made from high temperature thermoplastic, which provides durability in harsh environments.
The minimum operating temperature for this header is -40°C, making it suitable for a wide range of applications.
The contacts feature a tin termination type, which enhances their conductivity and reliability.
This product is made in the United States, reflecting its manufacturing origin.
