Samtec T1M Series Right Angle Surface PCB Header 20 Contacts 2 mm Pitch 2 Row Shrouded T1M-10-GF-DV-K
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.3A |
| Model | T1M-10-GF-DV-K |
| Mount Type | Surface |
| Housing Material | Natural LCP |
| Contact Material | Phosphor Bronze |
| Series | T1M |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -10°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Silver, Tin |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Row Pitch | 1mm |
Key Features
- Features a 2 mm pitch for precise connector spacing.
- Equipped with 20 male phosphor bronze contacts plated with silver and tin.
- Right angle orientation for surface mount applications.
- Constructed with natural Liquid Crystal Polymer housing for durability.
- Operates reliably between -10°C and 85°C.
- Rated for 250 V and 3.3 A current capacity.
- Two rows with 1 mm row pitch enhance compact board design.
- Shrouded connector system ensures secure mating and protection.
Product Description
Samtec T1M-10-GF-DV-K is a Right Angle Surface PCB Header featuring 20 male contacts arranged in 2 rows, each contact spaced at a 2 mm pitch. It operates at 250 V and supports a current of 3.3 A, making it suitable for a wide range of electronic applications requiring reliable wire-to-board interfacing.
The connector housing is made of natural Liquid Crystal Polymer (LCP), providing excellent thermal stability and mechanical strength across its operating temperature range of -10°C to 85°C. The contacts are made from phosphor bronze and plated with silver and tin, enhancing conductivity and corrosion resistance.
This model is shrouded to protect the contacts, and its right angle orientation is optimized for surface mount technology on printed circuit boards. The termination type is solder, aligning with standard PCB assembly processes.
The connector system is designed for wire-to-board connections and features two rows with a 1 mm row pitch, ensuring compact layout and efficient use of PCB space. The Samtec T1M series is widely used in electronics manufacturing, industrial control, telecommunications, and consumer electronics industries where quality and performance are critical.
2 mm pitch ensures accurate pin spacing. 20 male phosphor bronze contacts with silver and tin plating for durability. Natural LCP housing offers thermal and mechanical reliability. Shrouded design for secure and protected connections.
Right angle orientation suited for surface mount PCB applications. Voltage rating of 250 V and current rating of 3.3 A for robust performance. Operates reliably between -10°C and 85°C. Solder termination compatible with standard PCB assembly.
Two rows with 1 mm row pitch enhance compact design. Wire-to-board connector system ideal for diverse industrial applications.
Ideal for industrial electronics, telecommunications equipment, and embedded systems manufacturing. Explore more advanced PCB Headers and connectors in our Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 250 V, making it suitable for a variety of electronic applications.
This model supports a current capacity of 3.3 A, ensuring reliable performance in wire-to-board connections.
It operates reliably between -10°C and 85°C, allowing for use in various environments.
The T1M-10-GF-DV-K features 20 male contacts arranged in two rows.
The contacts are spaced at a 2 mm pitch, which ensures precise connector spacing.
The housing is constructed from natural Liquid Crystal Polymer (LCP), providing thermal stability and mechanical strength.
It uses solder termination, which is compatible with standard PCB assembly processes.
This model features a right angle orientation, optimized for surface mount applications.
The row pitch is 1 mm, enhancing compact board design.
The contacts are made from phosphor bronze and are plated with silver and tin for enhanced conductivity and corrosion resistance.
The T1M-10-GF-DV-K is a shrouded connector, which provides secure mating and protection for the contacts.
It is suitable for a wide range of applications in electronics manufacturing, industrial control, telecommunications, and consumer electronics.
