Samtec Straight Through Hole Shrouded PCB Header 34 Contacts 2 mm Pitch 2 Row EHT-117-01-S-D
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | EHT-117-01-S-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | EHT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 34 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Constructed with liquid crystal polymer housing for durability.
- Features 34 gold-plated phosphor bronze contacts ensuring reliable conductivity.
- Designed with a 2-row, 2 mm pitch configuration for wire-to-board connection.
- Mount type is through hole for secure PCB attachment.
- Operates within temperature range from -55°C to 125°C.
- Includes polarization notch and IDC ejector for secure cable locking.
- Termination type is solder for strong connection integrity.
Product Description
Samtec EHT-117-01-S-D is a high-quality shrouded straight through hole PCB header designed for industrial and commercial electronics applications. It features 34 contact points arranged in two rows with a precise 2 mm pitch, making it suitable for wire-to-board connections with reliable contact integrity.
The header housing is made from liquid crystal polymer, providing excellent chemical resistance and mechanical strength. Contacts are constructed from phosphor bronze and plated with gold, ensuring both conductivity and corrosion resistance, essential for long-term stability in harsh environments.
This connector is designed to operate over a wide temperature range from -55°C to 125°C, making it suitable for demanding industrial, HVAC, manufacturing, and laboratory equipment where temperature endurance is critical. The through-hole mount type offers sturdy PCB attachment, enhancing mechanical stability during vibration or movement.
Additional features include a polarization notch to prevent incorrect mating and an IDC ejector, facilitating secure cable lock and easy disconnection. Termination by solder ensures strong electrical and mechanical joint integrity.
This PCB header is ideal for use in electrical assemblies, power supplies, and specialized electronic modules where compact, reliable connectors are required. It supports wire-to-board interface needs and is engineered to the EHT series standards.
Constructed with liquid crystal polymer housing for durability. Features 34 gold-plated phosphor bronze contacts ensuring reliable conductivity. Designed with a 2-row, 2 mm pitch configuration for wire-to-board connection.
Mount type is through hole for secure PCB attachment. Operates within temperature range from -55°C to 125°C. Includes polarization notch and IDC ejector for secure cable locking. Termination type is solder for strong connection integrity.
Discover more high-performance PCB Headers and connectors at EnvMart to meet the demands of your electronic integration projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a 2-row configuration with a total of 34 contacts arranged in a 2 mm pitch, suitable for wire-to-board connections.
The contacts are made from phosphor bronze and are plated with gold, ensuring reliable conductivity and corrosion resistance.
It operates within a temperature range from -55°C to 125°C, making it suitable for various industrial applications.
This unit features a through-hole mount type, providing secure attachment to the PCB and enhancing mechanical stability.
The termination type is solder, which ensures strong electrical and mechanical joint integrity.
Yes, it includes a polarization notch to prevent incorrect mating and an IDC ejector for secure cable locking and easy disconnection.
The housing is constructed from liquid crystal polymer, providing excellent chemical resistance and mechanical strength.
The contacts are male, designed for wire-to-board applications.
This model is part of the EHT series, which is engineered for high-performance electronic applications.
The orientation of this model is straight, allowing for direct connections in electronic assemblies.
The country of origin for this PCB header is the United States, ensuring compliance with local manufacturing standards.
