Wurth Elektronik WR-MPC3 Series Right Angle Through Hole PCB Header, 8 Contact 3 mm Pitch, 1 Row, Shrouded MPC3
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 5A |
| Model | MPC3 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-MPC3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features right angle orientation for flexible PCB mounting.
- Copper alloy contacts plated with tin for superior conductivity.
- Rated for 5 amp current and 250 V voltage for robust electrical performance.
- Designed with a shrouded connector system for protection and safety.
- Through hole mount type suitable for robust soldering applications.
- Operates reliably in temperatures ranging from -40°C to 105°C.
- Complies with no specific certifications but constructed to high-quality standards.
Product Description
Wurth Elektronik MPC3 Right Angle Through Hole PCB Header is a high-quality electronic connector designed for wire-to-board applications. It features 8 male contacts arranged in a single row with 3 mm pitch spacing. The housing is made of Liquid Crystal Polymer (LCP), providing excellent mechanical and thermal stability in demanding environments.
The right angle orientation simplifies PCB layout by allowing perpendicular connections, which is ideal for space-constrained hardware designs. The contacts are copper alloy stamped and plated with tin to ensure low resistance and reliable electrical performance, supporting currents up to 5 A and voltages up to 250 V.
A shrouded design enhances connector protection and prevents accidental contact, increasing the durability and safety of the PCB assembly. The through-hole mounting type provides strong mechanical retention on printed circuit boards, suitable for industrial and commercial electronics manufacturing.
This component operates in a wide temperature range from -40°C to 105°C, making it suitable for industrial, telecommunications, computing, and automotive electronics usage contexts. Although there are no specific industry standards or approvals noted, Wurth Elektronik maintains high manufacturing quality.
Key features include robust solder terminations, a compact form factor due to the 3 mm pitch, and durable material selection for long service life. The product is manufactured in Taiwan, Province of China.
Features right angle orientation for flexible PCB mounting. Copper alloy contacts plated with tin for superior conductivity. Rated for 5 amp current and 250 V voltage for robust electrical performance. Designed with a shrouded connector system for protection and safety.
Through hole mount type suitable for robust soldering applications. Operates reliably in temperatures ranging from -40°C to 105°C. Complies with no specific certifications but constructed to high-quality standards.
This Wurth Elektronik WR-MPC3 PCB header is highly suitable for integration in electronics manufacturing lines where reliable and durable connectors are essential. Explore more PCB Headers and connectors in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 5 A.
It is rated for a maximum voltage of 250 V.
The contacts are made of copper alloy and are plated with tin for enhanced conductivity.
The contacts are arranged with a pitch of 3 mm.
This unit features a through hole mount type, suitable for robust soldering applications.
It operates reliably in temperatures ranging from -40°C to 105°C.
This model has 8 male contacts arranged in a single row.
The connector is designed with a right angle orientation, allowing for flexible PCB mounting.
It utilizes a wire-to-board connector system, which enhances connection reliability.
The housing is made from Liquid Crystal Polymer (LCP), providing excellent mechanical and thermal stability.
This model features a shrouded design, which enhances connector protection and safety.
It is manufactured in Taiwan, Province of China.
