Norcomp D-Sub Connector 15 Way Straight Panel Mount Male 2.286 mm Pitch 180-M15-103L001

Norcomp 180-M15-103L001 is a 15 way D-Sub connector designed for panel mount applications offering a straight orientation. It features a solder termination type suitable for secure PCB and wire connections, operating at a voltage rating of 1kV and current rating of 5A, making it ideal for various electronic and industrial applications.

The connector is engineered with a steel housing coated in nickel plating which provides strong EMI/RFI shielding to reduce interference in sensitive electronic circuits. The brass contacts are gold flash plated, enhancing conductivity and providing corrosion resistance, which ensures longevity and reliability in demanding conditions.

This connector supports a pitch of 2.286mm between contacts, accommodating fine pitch requirements. The insulator is made from glass-filled PBT thermoplastic capable of sustaining process temperatures up to 230°C, contributing to overall durability in high-performance settings. Its operating temperature range spans from -55°C to 105°C, making it suitable for both low and high-temperature environments commonly encountered in industrial, HVAC, telecommunications, and manufacturing sectors.

The Norcomp 180 series connectors are designed for high density and precision, offering approximately 65% higher density than standard D-Sub Connectors with screw machined contacts that ensure robust electrical performance and mechanical security. The metal shell includes clinch-nut options and grounding indents to facilitate secure retention and grounding in assemblies.

Panel mount male connector version 180-M15-103L001 is compatible with standard D-sub backshells and accepts wire gauges from 28 to 24, allowing flexible wiring solutions. Its compact design and dense pin configuration are excellent for use in electronic equipment, computers, instrumentation, control panels, and telecommunications systems.

Features high-density contacts and robust solder cup terminations for reliable electrical connections. Constructed with machined brass contacts plated with gold flash for superior durability. Metal nickel-plated steel shell provides effective EMI/RFI shielding.

Thermoplastic insulator rated for high temperature process up to 230°C ensures longevity. Designed for panel mount installation with straight orientation for ease of integration.

This product is designed to meet demanding industrial and electronic requirements, suitable for applications in computer hardware, telecommunications, aerospace, industrial control, and other technical fields. Norcomp connectors ensure precision, durability, and effective electrical performance, backed by rigorous manufacturing standards.
