Norcomp 15 Way Straight 2.286 mm Pitch Plug-in D-Sub Connector Female 780-M15-203L001
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.0kV |
| Brand | Norcomp |
| Orientation | Straight |
| Current | 5A |
| Model | 780-M15-203L001 |
| Mount Type | Plug-in |
| Housing Material | Steel |
| Contact Material | Brass |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.286mm |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
Key Features
- Supports 15 contacts suitable for complex signal transmissions.
- Rated for 5A maximum current capacity ensuring robust electrical performance.
- Constructed with steel housing for enhanced durability and shielding.
- Gold-plated brass contacts resist corrosion and maintain excellent conductivity.
- Operates within -55°C to 105°C temperature range for extreme environment applications.
- Plug-in mount type with solder termination offers secure and stable connections.
- Complies with IEC-529-IP67 sealing for dust and water resistance.
- Ideal for outdoor and industrial equipment requiring high reliability and protection.
Product Description
Norcomp 780-M15-203L001 is a 15 Way Straight 2.286 mm Pitch Plug-in D-Sub Connector Female designed to provide high-density and reliable electrical connections in demanding environments. Featuring a steel housing and gold-plated brass contacts, this D-Sub connector ensures robustness, excellent conductivity, and resistance to corrosion, making it suitable for industrial, medical, and commercial applications.
This connector supports a maximum current of 5A and operates reliably within a temperature range from -55°C to 105°C. Its plug-in solder termination type ensures secure and durable connections on PCBs. The IP67 sealed design complies with IEC-529 standards, providing resistance against dust, water, and temporary immersion, ideal for outdoor or washdown environments.
Norcomp's SEAL-D 780 series maintains the standard D-sub physical profile, facilitating easy upgrades to IP66/67 without the need to redesign enclosures or PCBs. Additional features include nickel-plated steel shells for superior shielding and ground indents to improve grounding and retention on the PCB.
This connector is well-suited for use in handheld computers, industrial and medical equipment, remote sensors, gas and water meter systems, and portable electrical generation devices. It is designed for demanding industrial settings requiring durability and reliable signal transmission.
Supports 15 contacts for complex connectivity needs. Current rating of 5A suitable for diverse electrical loads. Steel housing with nickel plating for superior shielding and protection. Gold-plated brass contacts ensure high reliability and conductivity.
IP67 sealed for protection against dust and temporary immersion. Plug-in solder termination type for strong, reliable mounting. Operates in temperature extremes of -55°C to 105°C. Standard D-sub form factor allows compatibility without redesign.
Ground indents for enhanced shielding and grounding stability.
Explore our extensive catalog of Norcomp D-Sub Connectors for industrial, laboratory, and commercial applications at EnvMart to meet your electronic connectivity requirements efficiently.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current capacity of 5A, suitable for diverse electrical loads.
It operates reliably within a temperature range of -55°C to 105°C, making it suitable for extreme environments.
This unit features a solder termination type, ensuring strong and reliable mounting on PCBs.
The connector supports 15 contacts, allowing for complex signal transmissions.
It is constructed with a steel housing and gold-plated brass contacts, providing durability and excellent conductivity.
Yes, it is IP67 sealed, providing protection against dust and temporary immersion in water, making it ideal for outdoor applications.
The pitch of this model is 2.286 mm, which is standard for D-Sub connectors.
It features a steel housing with nickel plating, which enhances shielding and protection.
This connector has a straight orientation, which is typical for D-Sub connectors.
It is well-suited for industrial, medical, and commercial applications, including handheld computers and remote sensors.
This model is rated for a voltage of 1.0kV, making it suitable for various electrical applications.
Yes, it complies with IEC-529-IP67 sealing standards, ensuring its effectiveness against dust and water ingress.
