ASSMANN WSW D-Sub Connector 37 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 37LPIII/Z

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW D-Sub Connector 37 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 37LPIII/Z

Name: ASSMANN WSW D-Sub Connector 37 Way Right Angle 2.54 mm Pitch Cable IDC Termination A-DFF 37LPIII/Z
Brand: ASSMANN WSW
SKU: 208267
Price: 3.71 USD
Availability: InStock



Category D-Sub Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	ASSMANN WSW
Orientation	Right Angle
Current	1A
Model	A-DFF 37LPIII/Z
Mount Type	Cable
Housing Material	Steel
Contact Material	Brass
Series	A-DFF
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	37
Contact Gender	Female
Connector Gender	Male/Female
Connector Type D	D-Sub

Key Features

37-way right angle D-Sub connector with cable mounting.
2.54 mm pitch spacing enables precise cable connections.
Steel housing with brass contacts plated gold over nickel.
Handles 250 V voltage and 1 A current ratings.
Operating temperature range from -55°C to 105°C.
IDC termination for fast and reliable cable assembly.
Male/female connector gender for versatile compatibility.

Product Description

ASSMANN WSW A-DFF 37LPIII/Z is a high-quality 37-way D-Sub connector designed for right angle orientation with a 2.54 mm pitch and cable mounting. It employs IDC (Insulation Displacement Contact) termination type, facilitating rapid and reliable cable assembly in electronic and industrial equipment.

The connector’s robust steel housing protects internal components and ensures mechanical stability, while brass contacts plated with gold over nickel provide excellent electrical conductivity and corrosion resistance. It supports a maximum current rating of 1 ampere and a voltage rating of 250 volts, making it suitable for low power signal connections.

Designed for demanding operating environments, it handles temperatures ranging from -55°C to 105°C, accommodating both cold storage and elevated heat conditions common in industrial settings.

The mixed connector gender of male and female contacts increases flexibility when integrating into various wiring harnesses or devices. This makes it ideal for applications in communications, instrumentation, and electronic manufacturing.

Right angle orientation with cable mounting to save PCB space and improve assembly layout. 37 contacts providing multi-signal conduction capability in compact form. IDC termination method reduces assembly time and improves connection reliability.

Durable steel housing and gold-plated contacts ensure longevity and low contact resistance. Wide operating temperature range supports usage across industrial sectors.

Manufactured under the A-DFF series, this connector originates from China with assured quality standards. It is a new product condition component optimized for integration into cables and electronic assemblies requiring dependable D-Sub connection solutions.
