Norcomp 15 Way Straight 2.286 mm Pitch Plug-in D-Sub Connector Female 780-M15-213R001

Norcomp 780-M15-213R001 is a 15 Way Straight Plug-in D-Sub Connector Female with a precise 2.286 mm pitch designed for robust electronic and power connector applications.

Constructed with a steel housing and nickel-plated shell, this connector provides excellent electromagnetic shielding and grounding via ground indents. The brass contacts are gold plated, ensuring resistance to corrosion and maintaining consistent electrical conductivity over time.

This D-Sub connector supports a current rating of 5A and voltage up to 1 kV, making it suitable for demanding power and signal transmission in various industrial and commercial systems. Its solder termination type allows for reliable, permanent connections.

Designed to meet IEC-529-IP67 standards, the connector seals against dust ingress and temporary water immersion, enabling use in harsh environmental conditions. The operational temperature range of -55°C to 105°C further enhances its adaptability for outdoor and industrial applications.

This connector's features include highly reliable screw machined contacts, a plug-in mount type, and a straight orientation female interface. These characteristics make it compatible with existing D-Sub footprints without requiring redesign of enclosures or PCBs when upgrading to IP67-rated solutions.

Common applications include hand-held computers, remote sensors, industrial and medical equipment, and portable electric generation devices. The robust construction and sealing performance allow this connector to be extensively used in outdoor instrumentation, gas/electric/watering meter systems, emergency beacons, and consumer boating electronics.

The connector has 15 gold-plated brass contacts rated for 5A current capacity. Steel housing with nickel plating provides superior shielding and grounding. Sealing meets IEC-529-IP67 requirements for environmental protection.

Suitable for solder termination and plug-in mount configurations. Operates reliably in temperatures ranging from -55°C to 105°C. Designed for industrial, medical, and outdoor applications. Maintains standard D-Sub profile reducing the need for enclosure redesign.

Manufactured in the United States ensuring high quality standards. Explore a full range of D-Sub Connectors at EnvMart for reliable industrial and commercial interconnect solutions.
