KEMET C4BS Film Capacitor, ±5 % Tolerance, 470 nF Capacitance, 2 kV DC, 700 V AC, Solder Lug Mount C4BS
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 40mm |
| Length | 41.5mm |
| Model | C4BS |
| Packaging | Bag |
| Width | 20mm |
| Mount Type | Solder Lug |
| Series | C4BS |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 470nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Tinned Brass Lug |
| Dissipation Factor | 0.0005% |
| Lead Length | 17mm |
| Standards/Approvals | EN 61071, IEC 61071, VDE 0560 |
| Package/Case | B |
| Rated AC Voltage | 700V ac |
| Rated DC Voltage | 2kV dc |
| Lead Pitch | 22mm |
| Equivalent Series Resistance ESR | 5.1mΩ |
Key Features
- This film capacitor is suitable for IGBT applications and protects against large voltage transients.
- The C4BS series features polypropylene metallised construction for durability and self-healing properties.
- It provides a dissipation factor of 0.0005%, ensuring minimal energy loss.
- The capacitor operates over a wide temperature range from -40°C to 85°C.
- Equipped with tinned brass lug terminals and a lead pitch of 22 mm for easy installation.
- Compact size with dimensions approximately 41.5 mm length, 20 mm width, and 40 mm height.
- Equivalent Series Resistance (ESR) is 5.1 mΩ, supporting efficient performance in power electronic circuits.
- Compliance with EN 61071, IEC 61071, and VDE 0560 standards ensures quality and safety.
Product Description
The KEMET C4BS Film Capacitor (Model: C4BS) is engineered for demanding electronic applications requiring stable capacitance and high voltage endurance. This capacitor boasts a capacitance value of 470 nF with a tolerance of ±5%, suitable for industrial, commercial, and automotive electronics including power modules and inverter circuits.
Its metallised polypropylene construction ensures excellent self-healing capabilities and outstanding high-frequency performance. Rated for 2 kV DC and 700 V AC, it effectively handles large voltage transients and ripple currents, making it ideal for gate turn-off protection in IGBT applications.
The solder lug mounting type facilitates firm mechanical and electrical connection, with tinned brass lug terminals and a 22 mm lead pitch complemented by 17 mm lead length for versatile PCB assembly. Operating temperature ranges from -40°C to 85°C ensure functionality across varied environmental conditions.
Physical dimensions measuring 41.5 mm length, 20 mm width, and 40 mm height maintain a compact profile suitable for space-constrained installations. The low Equivalent Series Resistance (ESR) of 5.1 mΩ enables better efficiency and lower heat generation during operation. Compliance with EN 61071, IEC 61071, and VDE 0560 standards affirms quality and safety adherence.
This film capacitor protects and stabilizes power electronic circuits under high voltage. It offers high contact reliability with metallised polypropylene technology. Its self-healing design extends component life by preventing permanent damage from electrical faults.
The component is supplied in a bag packaging to maintain quality during storage and transportation. Suitable for industrial electronics, power supply boards, and automotive control systems requiring robust, reliable capacitors.
Explore broader selections of Film Capacitors and related electronic components on EnvMart to support your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 470 nF with a tolerance of ±5%.
It is rated for 2 kV DC and 700 V AC, making it suitable for handling large voltage transients.
The operating temperature range for this unit is from -40°C to 85°C.
This model features a solder lug mount type, equipped with tinned brass lug terminals.
The physical dimensions are approximately 41.5 mm in length, 20 mm in width, and 40 mm in height.
The Equivalent Series Resistance (ESR) is 5.1 mΩ, which supports efficient performance in power electronic circuits.
It complies with EN 61071, IEC 61071, and VDE 0560 standards, ensuring quality and safety.
The dissipation factor is 0.0005%, which indicates minimal energy loss during operation.
The lead pitch for this capacitor is 22 mm, facilitating easy installation on PCBs.
The lead length is 17 mm, which aids in versatile PCB assembly.
The KEMET C4BS is supplied in bag packaging to maintain quality during storage and transportation.
It is suitable for industrial, commercial, and automotive electronics, including power modules and inverter circuits.
