Nexperia Schottky Diode 20 V 2 A 2-Pin SOD-323 Surface Mount PMEG2020AEA,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Schottky Diode 20 V 2 A 2-Pin SOD-323 Surface Mount PMEG2020AEA,115

Name: Nexperia Schottky Diode 20 V 2 A 2-Pin SOD-323 Surface Mount PMEG2020AEA,115
Brand: Nexperia
SKU: 162590
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.05mm
Length	1.8mm
Model	PMEG2020AEA,115
Width	1.35mm
Mount Type	Surface
Series	PMEG2020AEA
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	2A
Peak Reverse Repetitive Voltage Vrrm	20V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	200μA
Peak Non-Repetitive Forward Surge Current Ifsm	9A
Maximum Forward Voltage Vf	525mV

Key Features

This diode operates with a maximum continuous forward current of 2 amperes.
It features a peak reverse repetitive voltage of 20 volts ensuring reliable blocking capability.
The Schottky rectifier offers a low forward voltage drop of 525 millivolts to minimize power loss.
Peak non-repetitive forward surge current is rated at 9 amperes, allowing it to handle surge conditions.
With an operating temperature range from -65°C to 150°C, it suits demanding industrial environments.
The diode package is ultra-small and low profile, optimized for compact circuit boards.
Its automotive standard certification AEC-Q101 supports use in automotive electronics.
Low leakage current and capacitance make it suitable for high frequency applications.

Product Description

Nexperia PMEG2020AEA,115 Schottky Diode is a high-efficiency semiconductor component designed for surface mount technology applications with a 2-pin SOD-323 package.

This diode supports a maximum continuous forward current of 2 A and a peak reverse repetitive voltage of 20 V, making it suitable for rectification and protection circuits in various industrial and automotive electronic systems.

The device features a low forward voltage drop of 525 mV which reduces power dissipation, and a peak non-repetitive surge current of 9 A allowing brief handling of surge currents.

It operates reliably over a temperature range from -65°C to 150°C, making it resilient to harsh environmental conditions typically encountered in automotive and industrial electronic assemblies.

Its ultra-small, low profile package (1.8 mm x 1.35 mm x 1.05 mm) allows for compact PCB layouts and high-density assembly. This Schottky diode complies with automotive quality standard AEC-Q101, ensuring high reliability.

Low leakage current and minimal capacitance enhance performance in switching and high-frequency circuits. Optimized for low forward voltage drop and high junction temperature to improve energy efficiency and thermal management.

Common industrial applications include power rectification, voltage clamping, and reverse polarity protection in power supplies, automotive electronics, and communication devices. Set contains 1 Pc Nexperia PMEG2020AEA,115 Schottky Diode.
