Molex MicroClasp Series Straight Surface PCB Header 8 Contact, 2 mm Pitch, 2 Row, Shrouded 55917-0810

Molex 55917-0810 MicroClasp Series Straight Surface PCB Header is a high-quality double row vertical header designed for wire-to-board applications with a 2.00 mm pitch. Featuring 8 male contacts housed in durable polyester, this shrouded connector ensures secure and reliable board connections. Its brass contact material with tin plating provides excellent electrical conductivity and corrosion resistance, suitable for industrial and electronic equipment.

The header supports a current of up to 3A and is rated for operational temperatures from -40°C to 105°C, making it applicable in demanding environments such as manufacturing, electronics assembly, telecommunications, and instrumentation. The unique inner positive lock offers secure retention with an audible mating click to confirm proper connection, contributing to ease of use and assembly efficiency.

Designed for surface mount solder termination, the connector system optimizes PCB real estate with a compact 2 mm pitch and dual rows. The product's tail pin length of 3.2 mm and mating pin length of 2 mm align with industry standards for reliable solder joint formation.

Applications include electronic component assembly, industrial automation systems, communication devices, consumer electronics, and other scenarios where reliable wire-to-board connections are required. This component supports voltage up to 250V with a lance system interface for enhanced mounting stability and PCB space savings.

Current rating of up to 3A ensures reliable performance. Constructed with polyester housing for durability. Brass contacts plated with tin provide corrosion resistance. Designed for surface mount applications with solder termination type.

Operates reliably within -40°C to 105°C temperature range. Includes inner positive lock for secure mating and audible click confirmation. Compact 2.00 mm pitch saves PCB space. Male contact gender with 3.2 mm tail pin length and 2 mm mating pin length.

Voltage rated up to 250V for diverse applications. Wire-to-board connector system with latch protection mechanism. Explore our Electronics Components and PCB Headers category at EnvMart for a broad range of connectors and accessories suitable for your industrial and electronic applications.
