Samtec SSW Series Right Angle Through Hole PCB Socket, 10-Contact, 2 Row, 2.54 mm Pitch, 4.7A, 655V SSW-105-02-T-D-RA

Samtec SSW-105-02-T-D-RA is a high-quality right angle through hole PCB socket designed for board-to-board connector applications in industrial, electronic, and manufacturing environments. Featuring 10 female contacts arranged in 2 rows with a 2.54 mm pitch, this socket provides reliable and durable electrical connections.

The housing is molded from liquid crystal polymer, ensuring mechanical strength and thermal stability. The socket employs Tiger Buy™ contact technology renowned for high retention and cost-efficiency. Contact material is bronze with tin plating to enhance conductivity and resist corrosion. This socket supports up to 4.7A current and 655V voltage, making it suitable for moderate power applications.

The mount type is through hole with solder tail termination, providing a secure and long-lasting mechanical connection to printed circuit boards. Its right angle orientation is ideal for space-constrained PCB assemblies requiring board stacking or perpendicular connections.

The socket operates reliably within a temperature range of -55°C to 105°C, suitable for harsh industrial and electronic contexts. Both standard and low insertion force contact options are available to optimize mating with .025˝ square post terminals, enhancing ease of assembly and maintenance.

Features 10 female contacts arranged in 2 rows for compact design. Utilizes Tiger Buy™ contact system for high retention and cost efficiency. Constructed with liquid crystal polymer housing for durability. Supports 4.7A current and voltage up to 655V for robust electrical performance.

Solder tail termination with through-hole mount type ensures sturdy PCB fixing. Contact material is bronze with tin plating for corrosion resistance. Operating temperature range of -55°C to 105°C supports industrial environments.

Right angle orientation facilitates versatile board stacking. Pitch of 2.54mm and row pitch of 2.5mm match standard PCB layouts. Standard and low insertion force contacts optimize mating with .025” square post terminals.

This Samtec SSW Series PCB socket is ideal for industrial, electronics manufacturing, electronic assembly, and prototypes requiring reliable board-to-board connections. It is part of a broad range of PCB connectors and sockets designed to meet demanding technical specifications.
